Item Description Assembly
part number
Spare part
number
Customer
self repair
(on page 5)
a) 1-GB, PC2-6400 ECC RoHS* 499275-061 501156-001 Mandatory
1
b) 2-GB, PC2-6400 ECC RoHS* 499276-061 501157-001 Mandatory
1
c) 4-GB, PC2-6400 ECC RoHS* 499277-061 501158-001 Mandatory
1
d) 8-GB, PC2-5300 registered DDR2* 405478-071 432671-001 Mandatory
1
Cables
26 SAS backplane cable, 83.8 cm (33.0 in)* 463184-001 496070-001 Mandatory
1
27 SATA cable* 484355-005 496071-001 Mandatory
1
28 I/O cable* 463182-001 496072-001 Mandatory
1
29 Mini-SAS cable* 495973-005 507692-001 Mandatory
1
30 HD power cable* 463184-002 514217-001 Mandatory
1
31 AC power cord* 142263-001 142258-001 Mandatory
1
Rack mounting hardware
32 a) Rack mounting hardware kit* 487267-001 359254-001 Mandatory
1
b) LFF 491732-001 574898-001 Optional
2
c ) SFF 487267-001 574765-001 Optional
2
Miscellaneous
33 a) Battery, 3.3-V, lithium* 166899-001 153099-001 Mandatory
1
b) Power supply, 48v* 444049-001 451816-001 Optional
2
Options
34 Hot-plug hard drive* — — —
a) 36-GB, SAS, 10,000-rpm, 2.5-in 375859-B21 376596-001 Mandatory
1
b) 72-GB, SAS, 10,000-rpm, 2.5-in 375861-B21 376597-001 Mandatory
1
c) 60-GB SFF SATA hard drive, 5,400-rpm, 1
yr warranty*
379306-B21 382264-001 Mandatory
1
35 Array controllers — — —
a) Smart Array E200 Controller* 012891-001 412799-001 Optional
2
b) Smart Array E200 Controller cache module,
64-MB*
012970-001 412800-001 Optional
2
c) Smart Array E200 Controller cache module,
128-MB*
409248-001 413486-001 Optional
2
d) Smart Array P400 Controller* 013159-005 405831-001 Optional
2
e) Smart Array P400 Controller cache module,
256-MB*
012764-004 405836-001 Optional
2
f) Smart Array P400 Controller cache module,
512-MB*
012764-003 405835-001 Optional
2
g) Smart Array P400 Controller battery* 381573-001 398648-001 Optional
2
Illustrated parts catalog 21
