EL-MF877-00 Page 2
Template Revision A
2.0 Tools Required
List the type and size of the tools that would typically be used to disassemble the product to a point where components
and materials requiring selective treatment can be removed.
Tool Description Tool Size (if
applicable)
Torx Driver T-15 Bit
Philips Driver # 2
Flat Head Screw Driver Medium
3.0 Product Disassembly Process
3.1 List the basic steps that should typically be followed to remove components and materials requiring selective treatment:
1. System Board Battery – Remove the top cover and locate the battery on the system board. With a medium flat head
screw driver remove the battery and dispose of properly.
2. Capacitors > 2.5CM – Remove the power supply(s) from the system. With #2 Philips screw driver remove the screws
securing the top cover and the heatsinks in the P/S then locate the capacitors and pry from the PCB with a medium flat
head screw driver and dispose of properly.
3.
4.
5.
6.
7.
8.
3.2 Optional Graphic. If the disassembly process is complex, insert a graphic illustration below to identify the items
contained in the product that require selective treatment (with descriptions and arrows identifying locations).
Attachment 1 – Disassembly Diagram
Attachment 2 – System Battery Location
Attachment 3 – Capacitors Location
