34
Drive bay configuration
The server supports four drive bays—four drive bays for 3.5-inch non-hot-plug SATA hard disk drives
(HDD).
Go to the HP website at www.hp.com
and refer to the options list for this server model for the latest
information on supported system drives.
Item Description
1 Hard disk drive 1
2
Hard disk drive 2
3 Hard disk drive 3
4 Hard disk drive 4
System drive cable management
The figures in this section illustrate the system drives' data and power cable connections.
