Illustrated Parts Catalog

Table 1-1: Mechanical Components

Item Description Spare Part Number

Chassis

1 Front bezel 324713-001

2 Access panel 307549-001

a) Hood panel (right) —

b) Access panel (left) —

Miscellaneous

3 Hardware kit 325036-001

a) Hard drive compartment —

b) Media bay drive tray —

c) Expansion board knockout —

d) Hard drive screws —

e) Processor retention brackets* —

4 Miscellaneous plastics kit 176617-001

a) Air baffle —

b) Expansion slot retainer* —

c) Rubber bumpers* —

d) Removable media bezel blank* —

e) Cable clips* —

f) Miscellaneous clamps* —

g) LED shield* —

*Not shown

1-2 HP ProLiant ML330 Generation 3 Server Maintenance and Service Guide
