Illustrated Parts Catalog

Table 1-2: System Components

Item Description Spare Part Number

Mass Storage Devices

5 IDE CD-ROM drive, 48X 288894-001

6 Diskette drive 233409-001

7 Hard drive

a) 36-GB Wide Ultra3 hard drive, 10K RPM (SCSI model) 177986-001

b) 40-GB ATA hard drive (ATA model)* 232008-001

c) 18-GB Wide Ultra3 hard drive, 10K RPM (SCSI model)* 152191-001

d) 80-GB ATA hard drive (ATA model)* 287685-001

e) 160-GB ATA hard drive (ATA model)* 326510-001

Boards

8 PC2100 ECC Registered DDR SDRAM DIMM

a) 128-MB* 301691-001

b) 256-MB 300699-001

c) 512-MB* 300700-001

d) 1-GB* 300701-001

9 System board, 533-MHz front side bus 324709-001

10 Integrated Single Channel Ultra3 SCSI adapter 324710-001

11 Intel® Xeon

processor

a) 2.4-GHz*

b) 2.8-GHz

c) 3.06-GHz*

325034-001

324708-001

333055-001

Fans and Power

12 Heatsink/fan assembly 325035-001

13 System fan 324711-001

14 Power supply, 300 W, CE Mark-compliant 324714-001

15 CR2032 lithium battery 234556-001

16 Power cable kit 287181-001

a) Power button/LED assembly —

b) Power shield cable* —

c) Power extension cable* —

*Not shown

continued

1-4 HP ProLiant ML330 Generation 3 Server Maintenance and Service Guide
