Operations 26
CAUTION: For proper cooling do not operate the server without the access panel, baffles,
expansion slot covers, or blanks installed.
To remove the component:
1. Do one of the following:
o For tower models, open and remove the bezel ("Remove the tower bezel" on page 22).
o For rack models, if installed, remove the security bezel (on page 24).
2. Power down the server (on page 22).
3. Remove all power:
a. Disconnect each power cord from the power source.
b. Disconnect each power cord from the server.
4. Do one of the following:
o For tower models, place the server on a flat, level surface with the access panel facing up.
o For rack models, extend the server from the rack (on page 27).
5. Remove the access panel:
a. Open the locking latch.
If the locking latch is engaged, use a T-15 Torx screwdriver to unlock it.
b. Slide the access panel back.
c. Lift and remove the access panel.
Install the access panel
NOTE: If the rack bezel was removed, install it before installing the access panel.
