Access panel
The computer has one main rear access panel that allows access to internal components. Two screws secure
the access panel.
To remove the access panel:
1. Prepare the computer for disassembly (see Preparing to disassemble the computer on page 19).
2. Remove the rear port cover (see Rear port cover on page 23).
3. Remove the stand (see Attaching and removing a stand on page 20).
4. Pull up at the two recessed areas on at bottom of the access panel, and then lift the access panel o the
computer.
5. Lift the access panel o the computer.
To replace the access panel, reverse the removal procedures.
24 Chapter 4 Removal and Replacement Procedures
