Server component identification 13
Item Description
7 Optical device/multi-bay connector
8 Power supply connector
9 Power supply signal connector
10 Remote management connector
11 PCI riser board assembly connector (for slot 2 riser board)
12 PCI riser board assembly connector (for slot 1 riser board)
13 System battery
System maintenance switch
Position Default Function
S1 Off Off = iLO security is enabled.
On = iLO security is disabled.
S2 Off Off = System configuration can be
changed.
On = System configuration is
locked.
S3 Off Reserved
S4 Off Reserved
S5 Off Off = Power-on password is
enabled.
On = Power-on password is
disabled.
S6 Off Off = No function
On = ROM treats the system
configuration as invalid.
S7, S8 Off, Off Debug LEDs
