12 HP ProLiant DL360 Generation 4p Server (SAS Model) User Guide
Item Description Status
6 10/100/1000
NIC 1 activity
Green = Activity exists.
Flashing green = Activity exists.
Off = No activity exists.
7 Unit Identification
button/LED
Blue = Identification is activated.
Flashing blue = System is being managed
remotely.
Off = Identification is deactivated.
System board components
Item Description
1 DIMM slots (1-6)
2 NMI switch
3 System maintenance switch (SW2)
4 Processor socket 1
5 Processor socket 2
6 Processor zone fan module connector
To Next Page
