HP ProLiant ML310 G2 All Models
Standard Memory - Pentium 4 Models
512 MB PC3200 Unbuffered ECC DDR SDRAM installed (1 x 512 MB SDRAM DIMM)
Standard Memory Replaced with Optional Memory
Up to 4096 MB memory is available with the optional installation of PC3200 Unbuffered ECC DDR SDRAM DIMM Memory
kits.
These systems support PC3200 DDR memory and come standard with a single PC3200
DIMM installed.
The system board provides four DIMM sockets:
Socket 1 (blue connector), channel A
Socket 2 (black connector), channel A
Socket 3 (blue connector), channel B
Socket 4 (black connector), channel B
DIMMs do not need to be installed in pairs although installation of pairs (an equal DIMM for each channel) provides the best
performance. The BIOS will detect the DIMM population and set the system accordingly as follows:
Single-channel mode - DIMMs installed for one channel only
Dual-channel asymmetric mode - DIMMs installed for both channels but of unequal channel capacities.
Dual-channel interleaved mode (recommended) - DIMMs installed for both channels and offering equal channel
capacities, proving the highest performance.
These systems require DIMMs with the following parameters:
Unbuffered
256 MB, 512 MB, and 1 GB memory technology
PC3200
ECC DIMMs only
The first DIMM should be installed in Socket 1. A DIMM should not be installed in Socket 2 without a DIMM in Socket.
Likewise a DIMM should not be installed in Socket 4 without a DIMM in Socket 3. A DIMM need not be installed in Socket 2
in order to install a DIMM in Socket 3.
The table below shows some of the suggested memory configurations for these systems.
NOTE: Table below does not list all possible configurations. Balanced-capacity, dual-channel loading yields best
performance.
Channel A Channel B
Total Mode
Socket 1 Socket 2 Socket 3 Socket 4
256 MB none none none 256 MB Single-channel
256 MB none 256 MB none 512 MB Dual-channel
interleaved
512 MB none none none 512 MB Single-channel
512 MB none 512 MB none 1 GB Dual-channel
interleaved
1 GB none none none 1 GB Single-channel
1 GB none 1 GB none 2 GB Dual-channel
interleaved
1 GB 1-GB 1 GB none 3 GB Dual-channel
asymmetric
1 GB 1-GB 1 GB 1 GB 4 GB Dual-channel
interleaved
