HP SCSI

System Unit Dimensions (HxWxD) 17.0 x 7-7/8 x 22 in (43.0 x 20.0 x 55.0 cm)
Weight (approximate) 37 lb (16.8 kg)
Input Requirements
(per power supply)
Range Line Voltage 100-127V and 200-240V
Normal Line Voltage 115 to 230 VAC
Line Frequency 50 to 60 Hz
Rated Input Current < 6A RMS at 90VAC with maximum load
BTU Rating 1,560 BTU
SCSI Connectors
(SCSI Models only)
One internal HD68 connectors
NOTE: Support for either one internal or one external SCSI channel is
available. This is achieved using an internal to external SCSI cable
option kit (PN 159547-B22) and SCSI knockout bracket.
Power Supply Output
Power
Rated Steady-State
Power
350W
Maximum Peak Power 370W
Temperature Range Operating 50° to 93° F (10° to 35° C)
Shipping -40° to 150° F (-40° to 66° C)
Relative Humidity
(non-condensing)
Operating 20% to 80%
Non-operating 5% to 90%
Acoustic Noise Idle
(Fixed Disk Drives
Spinning)
L WAd (BELS) 5.7
L pAm (dBA) 40
Operating
(Random Seeks to Fixed
Disks)
L WAd (BELS) 5.7
L pAm (dBA) 40
Non-Hot Plug Wide
Ultra320 SCSI Hard
Drives
36.4 GB 15K Capacity 36419.2 MB
357012-B21 Height 1 in (2.54 cm)
Width 4 in (10.16 cm)
Interface Ultra320 SCSI
Transfer Rate
Synchronous
(Maximum)
320 MB/s
Seek Time
(typical reads, including
settling)
Single Track 0.4 ms
Average 3.8 ms
Full-Stroke 8 ms
Rotational 15,000 rpm
Physical Configuration Bytes/Sector 512
Logical Blocks 71,132,000
Operating Temperature 50° to 95° F (10° to 35° C)
QuickSpecs
HP ProLiant ML310 Generation 2
Technical Specifications
DA - 12168 Worldwide QuickSpecs — Version 28 — 3-24-2006 Page 31
