HP SmartMemory - Page 11

POPULATED DIMM SPEED (MT/s)
1 DIMM
Per
Channel
1600 1866 1600 1866 1600 1866 1600 1866 1866 1600 1866 1600 1866 1600 1866
2 DIMM
Per
Channel
1600 1866 1600 1866 1600 1866 1600 1866 1866 1600 1866 1600 1866 1600 1866
3 DIMM
Per
Channel
800 1066 800 1066 800 1066 800 1066 1333 n/a n/a n/a n/a n/a n/a
Memory speed is a function of the processor QPI bus speed.
* Maximum capacity will vary based on individual server platform qualification schedule
For HP SmartMemory, UDIMM is supported at 2DPC@DDR3-1866. Third party memory may only support up to 2DPC@DDR3-1333 or
1600.
# All configurations on 64 slot server run at DDR3-1066.
Intel Gen8 Supported Memory Bandwidth for HP ProLiant Gen8 Intel® Xeon® E5-2XXX Series Processor Family
DIMM Type
-> Registered Dimms (RDIMMs)
Load
Reduced
(LRDIMMs)
Unbuffered with ECC DIMMs
(UDIMMs)
DIMM Rank
->
Single Rank (1R) Dual
Rank
(2R)
Dual
Rank
(2R)
Single
Rank
(1R)
Dual
Rank
(2R)
Dual
Rank
(2R)
Three
Rank
(3R)
Quad
Rank (4R)
Single
Rank
(1R)
Single
Rank
(1R)
Dual
Rank
(2R)
Dual
Rank
(2R)
DIMM
Capacity ->
4GB 4GB 8GB 8GB 8GB 16GB 16GB 24GB 32GB 2GB 2GB 4GB 4GB
DIMM
Native
Speed
(MT/s) - >
1333 1600 1333 1600 1600 1333 1600 1333 1333 1333 1600 1333 1600
Voltage LV Std LV Std Std LV Std LV LV LV Std LV Std
SLOTS THAT CAN BE POPULATED
12 slot
servers
12 12 12 12 12 12 12 n/a 12 12 12 12 12
16 slot
servers
16 16 16 16 16 16 16 16 ***** 16 16 16 16 16
24 slot
servers
24 24 24 24 24 24 24 n/a 24 16 16 16 16
32 slot
server
32 32 32 32 32 32 32 32 ****** 32 n/a n/a n/a n/a
48 slot
servers
48 48 48 48 48 48 48 n/a 48 n/a n/a n/a n/a
QuickSpecs
HP SmartMemory
Technical Specifications
DA - 14225 Worldwide — Version 11 — October 8, 2013 Page 11
