HP SmartMemory - Page 13

AMD Gen8 Supported Memory Bandwidth
DIMM Type -> Registered Dimms (RDIMMs) Load Reduced
(LRDIMMs)
DIMM Rank -> Single Rank (1R) Dual Rank (2R) Quad Rank (4R)
DIMM Capacity -
>
4GB 4GB 8GB 8GB 16GB 16GB 32GB
DIMM Native
Speed (MT/s) -
>
1333 1600 1600 1333 1333 1600 1066
Voltage LV/ULV Std Std LV/ULV LV/ULV Std LV
SLOTS THAT CAN BE POPULATED
16 slot servers 16 16 16 16 16 16 16
24 slot servers 24 24 24 24 24 24 24
MAXIMUM CAPACITY (GB) *
16 slot servers 64 64 128 128 256 256 512
24 slot servers 96 96 192 192 384 384 768
POPULATED DIMM SPEED (MT/s)
1 DIMM Per
Channel
1333 1600 1600 1333 1333 1600 1333
2 DIMM Per
Channel
1333 1600 1600 1333/ 1066
2
1333/ 1066
2
1600 1333
3 DIMM Per
Channel
1066 1066 1066 1066/ 800
3
1066/ 800
3
1066 800
4
1
Maximum capacity will vary based on individual server platform.
2
Ultra Low Voltage 8GB and 16GB dual rank operate at 1066MT/s speed in 2 DPC configurations.
3
Ultra Low Voltage 8GB and 16GB dual rank operate at 800MT/s speed in 3 DPC configurations.
4
LRDIMM capable of 3 DIMMs per channel.
Memory Speed by Processor Model
HP ProLiant Gen8 Intel® Xeon® E5-2600 Series Processor Family:
Processor Models Supported Memory Speeds
E5-2690, E5-2680, E5-2670, E5-2667, E5-2665, E5-2660, E5-2650, E5-2650L, E5-2643, E5-
2637, E5-2537
1600/1333/1066MHz
E5-2640, E5-2630, E5-2630L, E5-2620 1333/1066MHz
E5-2609, E5-2603 1066MHz
QuickSpecs
HP SmartMemory
Technical Specifications
DA - 14225 Worldwide — Version 11 — October 8, 2013 Page 13
