HP SN3000B Fibre Channel Switch
c04111465 – DA – 14277 Worldwide — Version 12 — June 10, 2014
One USB port for system log file downloads or firmware upgrades
Simple Name Server (SNS); Registered State Change Notification (RSCN),
NTP, RADIUS, RCS (Reliable Commit Service), Dynamic Path Selection (DPS),
Brocade Advanced Zoning, WEB TOOLS™. Optional Fabric Services include:
Fabric Watch™, Extended Fabrics, ISL Trunking, End-to-End Performance
Monitoring (APM) and Adaptive Networking with QoS.
Management software
supported
SSH v2, HTTP/HTTPS, SNMP v1/v3, Telnet; SNMP;
WEBTOOLS, B-series SAN Network Advisor, SMI-S, RADIUS, LDAP.
10/100 Mbps Ethernet (RJ-45), in-band over Fibre Channel, serial port (RJ-
45), and one USB port
POST and embedded online/offline diagnostics including FCPing, Pathinfo
(FCTraceroute), Forward Error Correction (FEC), etc. Diagnostic Port (D-
Port) diagnostic features for physical link trouble shooting
Port Side exhaust airflow; power from back; 1U
Width: 438 mm (17.23 in.)
Height: 43 mm (1.7 in.)
Depth: 443 mm (17.45 in.)
7.82 kg (17.25 lb) with one power supply, without transceivers
Operating: 0° to 40° C (32° to 104° F)
Non-operating: -25° to 70° C (-13° to 158° F)
Operating: 10 to 85 percent non-condensing
Operating: Up to 3000 meters (9,842 feet)
Storage: Up to 12 kilometers (39,370 feet)
Operating: 20 g, 6 ms half-sine
Non-operating: Half sine, 33G 11ms. 3/eg Axis
Operating: 0.5 g sine, 0.4 grms random, 5 to 500 Hz
Non-operating: 2.0 g sine, 1.1 grms random, 5 to 500 Hz
Single power supply with integrated system cooling fan; Optional hot-
swappable dual redundant power supply
85 V to 264 V ~5 A to 2.5 A
80 watts with all 24 ports populated with
16 Gbps SWL optics
60 watts for empty chassis with no optics
