Detailed Information
Detailed information displays for this operation, as shown in Table 204.
Table 204 Replace Operation
DescriptionItem
The name of the parts (EPOSW, PCICON, PCIADP, DKCPANEL, PSxx, PS-xx, BATTERY-xx,
ACBOX-x, FAN-xx, TH-xx, SSVP/MN, SVP, HDDFANxx-x, BATTERY-Uxxx, BATREG-x,
FUSE-xxx, ACBOX-Uxxx, DKUPS-xxx, SVRxxx-x, SVRxxx-Ex, EXTADP, BATTERY-SBx,
SBADP, or LEDPNLxx-x) specified to be replaced.
Parts name
The port which Small Form-Factor Pluggables (SFPs) are inserted.SFP
The number of inserted Small Form-Factor Pluggables (SFPs).Num.of SFPs
The mounting location of the PCB, (Channel Adapter (CHA), Disk Adapter (DKA), cache
memory, CM, SM, cache switch, MIX or BASE) to be replaced.
PCB
When replacing multiple PCBs and some of the PCBs to be replaced had failures, the
mounting locations of the failed PCBs are indicated. In such case, Warning is output as
the result of the process.
NOTE:
This information is not output when there are no failed PCBs.
Failed
The number of PCBs to be replaced.Num. of PCBs
The mounting location of the PDEVs (physical devices) to be replaced.
Physical Device
(PDEV)
The status of copy process when replacing physical devices (PDEVs). This information is
output only when replacing PDEVs.
Restore Data: Data recovery from spare disk, Correction Copy: correction copy
Copy
Diagnosis is output only when INLINE skip is selected when replacing PDEVs. This
information is output only when replacing PDEVs.
Diagnosis
Micro Program is output only when microcode update is skipped when replacing PDEVs.
This information is output only when replacing PDEVs.
Micro Program
The number of PDEVs to be replaced. This information is output only when easy replacing
PDEVs.
Num. of PDEV
The mounting location of fibre switches to be replaced.FSW
The number of fibre switches to be replaced.Num. of FSWs
Restore Operation
Example 1 (restoring a PCB)
