Tablet major components
Item Component Spare part number
(1) Back cover 796782-001
(2) Mid-frame cover 796783-001
(3) Front-facing webcamera (includes cable) 796786-001
(4) Battery, 3000 mAh, USB-charging (includes cable) 795065-001
(5) Rear-facing webcamera (includes cable) 796787-001
(6) Speaker Kit (includes speaker and cables); the speaker is also spared with the system
board
796788-001
(7) Antenna board (includes WLAN antenna cable and transceiver) 796789-001
(8) Speaker rubber protector 796792-001
4 Chapter 3 Illustrated parts catalog
