Volume control button
Description Spare part number
Volume control button 796794-001
Before removing the volume control button, follow these steps:
1. Turn off the tablet. If you are unsure whether the tablet is off or in Hibernation, turn the tablet on, and
then shut it down through the operating system.
2. Disconnect the power from the tablet by unplugging the power adapter cord from the tablet.
3. Disconnect all external devices from the tablet.
4. Remove the back cover (see Back cover on page 13).
5. Remove the mid-frame cover (see Mid-frame cover on page 14).
6. Disconnect the battery (see Battery on page 15).
7. Remove the power button board (see Power button board on page 26).
Remove the volume control button:
Lift the volume control button.
Reverse this procedure to install the volume control button.
28 Chapter 5 Removal and replacement procedures

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP Stream 7 and is the answer not in the manual?

HP Stream 7 Specifications

General IconGeneral
Display Size7 inches
Resolution1280 x 800 pixels
ProcessorIntel Atom Z3735G
RAM1 GB
Storage32 GB
Battery Capacity3000 mAh
Front Camera0.3 MP
Rear Camera2 MP
Wireless802.11b/g/n
BluetoothBluetooth 4.0
Operating SystemWindows 8.1
Expandable StoragemicroSD, up to 32 GB
PortsMicro-USB 2.0, 3.5mm headphone jack
