8. If it is necessary to replace the display panel cable:
a. Release the display panel cable from the retention clips (1) and channel built into the left side of
the display back cover.
b. Remove the display panel cable (2).
The display panel cable includes the webcam/microphone module cable and is available using
spare part number 905561-001.
IMPORTANT: Be sure to note the way the cable routes into the display hinge, as shown in the
following image.
9. If it is necessary to replace the WLAN antenna cable and transceiver:
a. Release the antenna cable from the retention clips (1) and channel built into the right side of the
display back cover.
Component replacement procedures 41
