HP t620 PLUS User Manual

12. To remove a SODIMM, press outward on the two latches (1) on each side of the SODIMM,
rotate the SODIMM up (2), and then pull the SODIMM out of the socket (3).
13. Slide the new SODIMM (1) into the socket at approximately a 30° angle, and then press the
SODIMM into the socket (2) so that the latches lock it in place.
NOTE: A memory module can be installed in only one way. Match the notch on the module
with the tab on the memory socket.
20 Chapter 2 Hardware changes

HP t620 PLUS Specifications

General

L2 cache	2 MB
Processor cores	4
Processor model	GX-420CA
Processor family	AMD G
Motherboard chipset	-
Processor frequency	2 GHz
Storage media	SSD
Card reader integrated	No
Total storage capacity	16 GB
Storage drive interface	mSATA
Internal memory	4 GB
Memory clock speed	1600 MHz
Internal memory type	DDR3L-SDRAM
Discrete graphics card model	AMD FirePro 2270
On-board graphics card model	AMD Radeon HD 8400E
Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
USB 2.0 ports quantity	6
Ethernet LAN (RJ-45) ports	1
VGA (D-Sub) ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Operating system installed	ThinPro
Operating system architecture	32-bit
Product color	Black
Power supply	85 W
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Sustainability certificates	ENERGY STAR
Country of origin	China

Weight and Dimensions

Depth	65 mm
Width	220 mm
Height	240 mm
Weight	2040 g
