HP t620 PLUS User Manual

Rear panel components
For more information, go to http://www.hp.com and search for your specific thin client model to find
the model-specific QuickSpecs.
(1) Half-height PCIe 2.0 expansion slot* (8) PS/2 keyboard port
(2) Serial port* (9) PS/2 mouse port
(3) Parallel port* (10) Serial port
Optional: VGA port or fiber NIC port
(4) Retractable power cord retention hook (11) Audio line-in port
(5) Ethernet RJ-45 port (12) Audio line-out port
(6) USB 2.0 ports (2) (13) Power
(7) Dual-mode DisplayPort 1.2 ports (2) (14) Cable lock slot
*Available on some models. Refer to the model-specific QuickSpecs at www.hp.com for details.
The devices connected at boot up or subsequently disconnected determine which video ports are
enabled and which is disabled.
●
If a VGA device is connected at boot up, then only one DisplayPort port may be used. If the VGA
device is subsequently disconnected, then both DisplayPort ports are enabled.
●
If a VGA device and one DisplayPort device are connected at boot up, then the other
DisplayPort port is disabled. If the VGA device is subsequently disconnected, then that
DisplayPort port is enabled.
● If two DisplayPort devices are connected at boot up, then the VGA port is disabled. If one or
both DisplayPort devices are subsequently disconnected, the VGA port is enabled.
Rear panel components 3

HP t620 PLUS Specifications

General

L2 cache	2 MB
Processor cores	4
Processor model	GX-420CA
Processor family	AMD G
Motherboard chipset	-
Processor frequency	2 GHz
Storage media	SSD
Card reader integrated	No
Total storage capacity	16 GB
Storage drive interface	mSATA
Internal memory	4 GB
Memory clock speed	1600 MHz
Internal memory type	DDR3L-SDRAM
Discrete graphics card model	AMD FirePro 2270
On-board graphics card model	AMD Radeon HD 8400E
Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
USB 2.0 ports quantity	6
Ethernet LAN (RJ-45) ports	1
VGA (D-Sub) ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Operating system installed	ThinPro
Operating system architecture	32-bit
Product color	Black
Power supply	85 W
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Sustainability certificates	ENERGY STAR
Country of origin	China

Weight and Dimensions

Depth	65 mm
Width	220 mm
Height	240 mm
Weight	2040 g
