HP t620 User Manual

Rear panel components
For more information, go to http://www.hp.com and search for your specific thin client model to find
the model-specific QuickSpecs.
(1) Half-height PCIe 2.0 expansion slot* (8) PS/2 keyboard port
(2) Serial port* (9) PS/2 mouse port
(3) Parallel port* (10) Serial port
Optional: VGA port or fiber NIC port
(4) Retractable power cord retention hook (11) Audio line-in port
(5) Ethernet RJ-45 port (12) Audio line-out port
(6) USB 2.0 ports (2) (13) Power
(7) Dual-mode DisplayPort 1.2 ports (2) (14) Cable lock slot and rear cover latch
*Available on some models. Refer to the model-specific QuickSpecs at www.hp.com for details.
If the configurable port (item #10) is VGA, then the devices connected at boot up or subsequently
disconnected determine which video ports are enabled and which is disabled.
ł
If a VGA device is connected at boot up, then only one DisplayPort port may be used. If the VGA
device is subsequently disconnected, then both DisplayPort ports are enabled.
ł
If a VGA device and one DisplayPort device are connected at boot up, then the other DisplayPort
port is disabled. If the VGA device is subsequently disconnected, then that DisplayPort port is
enabled.
ł
If two DisplayPort devices are connected at boot up, then the VGA port is disabled. If one or both
DisplayPort devices are subsequently disconnected, the VGA port is enabled.
2 Chapter 1 Product features

HP t620 Specifications

General

L2 cache	1 MB
Processor cores	2
Processor model	GX-217GA
Processor family	AMD G
Motherboard chipset	-
Processor frequency	1.65 GHz
Storage media	SSD
Card reader integrated	No
Total storage capacity	32 GB
Internal memory	4 GB
Memory clock speed	1600 MHz
Internal memory type	DDR3L-SDRAM
On-board graphics card model	AMD Radeon HD 8280E
Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
USB 2.0 ports quantity	6
Ethernet LAN (RJ-45) ports	1
VGA (D-Sub) ports quantity	0
Operating system installed	Windows Embedded 8 Standard
Operating system architecture	64-bit
Product color	Black
Power supply	65 W
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Country of origin	China

Weight and Dimensions

Depth	40 mm
Width	220 mm
Height	240 mm
Weight	1360 g
