HP t620 User Manual

ł
Attach the stand to the right side of the computer to use it in the horizontal orientation.
a. Lay the computer down with the right side up and locate the two screw holes in the grid
on the right side of the computer.
b. Position the stand (1) over the side of the computer and line up the captive thumbscrews
in the stand with the screw holes in the computer.
c. Tighten the captive thumbscrews (2) securely.
6. Reconnect the external equipment, plug the power cord into a power outlet, and then turn the
computer on.
NOTE: Be sure that at least 10.2 centimeters (4 inches) of space on all sides of the computer
remain clear and free of obstructions.
NOTE: An optional Quick Release mounting bracket is available from HP for mounting the computer
to a wall, desk, or swing arm. When the mounting bracket is used, do not install the computer with the
I/O ports oriented towards the ground.
Attaching the stand
7

HP t620 Specifications

General

L2 cache	1 MB
Processor cores	2
Processor model	GX-217GA
Processor family	AMD G
Motherboard chipset	-
Processor frequency	1.65 GHz
Storage media	SSD
Card reader integrated	No
Total storage capacity	32 GB
Internal memory	4 GB
Memory clock speed	1600 MHz
Internal memory type	DDR3L-SDRAM
On-board graphics card model	AMD Radeon HD 8280E
Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
USB 2.0 ports quantity	6
Ethernet LAN (RJ-45) ports	1
VGA (D-Sub) ports quantity	0
Operating system installed	Windows Embedded 8 Standard
Operating system architecture	64-bit
Product color	Black
Power supply	65 W
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Country of origin	China

Weight and Dimensions

Depth	40 mm
Width	220 mm
Height	240 mm
Weight	1360 g
