HP TFT7600 User Manual

Introduction 7
Callout Component Function
8 USB connection Pass-through to the rear USB port
9 Scroll bar Used to scroll on the monitor
10 Right pick button Used to select the option on the right
11 Middle pick button Used to select the option in the middle
12 Left pick button Used to select the option on the left
13 Touchpad Used to move the mouse on the monitor
Rear components
Callout Component
1 USB pass-through
2 USB keyboard and mouse port
3 PS2 keyboard port
4 PS2 mouse port
5 VGA input port
6 Power connection port
7 Serial firmware port

HP TFT7600 Specifications

General

Display Size	17 inches
Native Resolution	1280 x 1024
Brightness	250 cd/m²
Video Input	VGA
Aspect Ratio	5:4
Panel Type	TFT LCD
Viewing Angle	160° horizontal, 160° vertical
Weight	11.3 kg
