Installation 8

Installation

Kit contents

Item Quantity

HP TFT7600 KVM Console 1

M6 screws 4

6-32 screws 5

HP Adjustable Toolless Rails 2

Cable management arm, power adapter with brace rail 1

Lock plates 2

USB cables 2

PS2 cables 2

Video cable 1

Power cords 2

USB cable labels 2

This kit might contain extra hardware.

Installing the HP TFT7600 G2 Rackmount Keyboard

Monitor KVM Console

1. Align the HP 1U Adjustable Toolless Rails with the holes marked on the rack, and snap them into

place.

a. Snap one end of the HP 1U Adjustable Toolless Rails into the retna rails.

b. Extend the other half of the HP 1U Adjustable Toolless Rails to meet the appropriate rack depth,

and snap them into place.

NOTE: If the HP 1U Adjustable Toolless Rails do not snap into place, be sure that they align

with the holes marked on the rack. The holes marked on the rack must be in the same location

for the front and rear of the rack.
