HP U27 User Manual

EL-MF877-00 Page 19
Template Revision C
Last revalidation date 13-April-2020
HPI instructions for this template are available at EL-MF877-01
the input
Image appears
blurred,
indistinct, or too
dark.
Brightness is too low. Open the OSD menu and
select Brightness to adjust
the brightness scale as
needed.
Check Video
Cable
is displayed
on screen.
Monitor video cable is disconnected. Connect the appropriate
video signal cable between
the computer and monitor.
Be sure that the computer
power is off while you
connect the video cable.
Input Signal Out
of Range is
displayed on
screen.
Video resolution and/or refresh rate are set higher
than what the monitor supports.
Change the settings to a
supported setting.
The monitor is
off, but it did not
seem to enter
into Sleep mode.
The monitor’s power saving control is disabled. Open the OSD menu and
select Power Control >
Auto-Sleep Mode and set
auto-sleep to
On
.
On-
Screen Menus
are Locked is
displayed.
The monitor’s OSD lock function is enabled.
Press and hold the Menu
button on the front bezel to
10 seconds to disable the
OSD lockout function.
Power Button is
Locked is
Displayed
The monitor’s power button is locked.
Press and hold the power
button for 10 seconds to
disable the power button
lock function.

HP U27 Specifications

General

Pixel pitch	0.155 x 0.155 mm
Screen shape	Flat
Pixel density	163 ppi
Display diagonal	27 \
Display technology	LED
Native aspect ratio	16:9
Vertical scan range	40 - 60 Hz
Maximum refresh rate	60 Hz
Horizontal scan range	31 - 135 kHz
Contrast ratio (typical)	1000:1
Display number of colors	-
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 3840 x 2160
Headphone out	Yes
USB hub version	3.2 Gen 1 (3.1 Gen 1)
DisplayPort version	1.2
USB Type-A downstream ports quantity	3
Certification	BSMI; CB; CCC; CE; CSA; CSA-NRTL; EAC; EUP Lot-6; FCC; GEMS; HRN N N0.201; ICES; IS 1121; KC/KCC; PSB; RCM; SABS IEC 60950-1; SASO; TUV Bauart; VCCI; ISC; EUP Lot-26; IEC 60950:1999; eStandby; MEPS (HP) UKRAINIA; ISO 9241; China CEL
Market positioning	Home
Tilt angle range	-5 - 16 °
Panel mounting interface	100 x 100 mm
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Package type	Box
Package depth	125 mm
Package width	699 mm
Package height	462 mm
Package weight	7450 g
AC input voltage	100 - 240 V
Power consumption (standby)	0.3 W
Power consumption (typical)	46.2 W
Cables included	AC, HDMI

Weight and Dimensions

Depth (with stand)	193.5 mm
Height (with stand)	501.3 mm
Weight (with stand)	5000 g
Depth (without stand)	53.2 mm
Width (without stand)	613.5 mm
Height (without stand)	366.5 mm
