ENWW Front-Panel Controls 11
Front-Panel Controls
The monitor buttons are located on the bottom of the front panel
Figure 4-1 Front-panel control buttons
No. Icon Description
1 Power Turns the monitor on or puts it in standby or sleep mode. The Power
button is located on the bottom or front of the monitor depending on the
model.
2 OK If the OSD menu is on, press to select the highlighted menu item.
If the OSD menu is inactive, press to activate the auto adjustment feature
to optimize the screen image.
3 + If the OSD menu is on, press to navigate forward through the OSD menu
and increase adjustment levels.
If the OSD menu is inactive, press to activate the source button that
chooses the video signal input (VGA or DVI)
4 - If the OSD menu is on, press to navigate backward through the OSD
menu and decrease adjustment levels.
If the OSD menu is inactive, press to activate the volume adjustment bar,
press - or + to adjust volume.(with audio model only)
5 Menu Opens, selects, or exits the OSD menu.
Menu
OK
12345
