4. Input/Output Specification
4.1 Input Signal Connector
PIN MNEMONIC SIGNAL PIN MNEMONIC SIGNAL
1 RV Red Video 9 +5 V +5 V (from PC)
2 GV Green Video 10 SG Sync Ground
3 BV Blue Video 11 NC
None (Reserved for
Factory Use)
4 NC
PC Connect detection
12 SDA DDC Data
5 GND
Ground (DDC Return)
13 HS Horizontal Sync
6 RG Red GND 14 VS Vertical Sync
7 GG Green GND 15 SCL DDC Clock
8 BG Blue GND
1.
Brightness
Adjust the brightness.
2. Contrast Adjust the contrast
3.
Control
Adjust the:
z Auto Adjustment: Adjusts the main settings and produces a stable,
centered image.
z H-Position: horizontal position of the screen image.
z V-Position: vertical position of the screen image.
z Clock: frequency of the pixel clock to minimize vertical bar.
z Phase: phase value to minimize horizontal jitters.
4. Volume Adjust the volume
5. Color
z 9300K: recall 9300K colo
r
z 6500K: recall 6500K color
z SRGB: recall SRGB color
z Custom Color: adjusts the color tint of white, and the red, green, and
blue
(
RGB
)
mix for colors.
6. Language Shows the language of the OSD window.
7.
Management
z Power Saver: enable/disable power saving
z Power On Recall: enable/disable power recall
z Mode Display: enable/disable mode display
z Sleep Timer: set sleep timer
z Basic Menu: set to basic menu
8.
OSD Control
OSD (on Screen Display) settings: adjusts the H/V position, timeout, On
Screen Display window.
9.
Information
Current setting, recommended setting, serial number, total hours,
backlight hours, Exit.
10.
Factory
Reset
Resets the display to original factory settings for color, brightness,
phase, and clock.
11.
Exit Exit the current OSD window.
