HP VS17E User Manual

HP VS17E
4
1.Monitor Specification
Items Description
LCD Panel
Driving system TFT Color LCD
Panel LTM170EU-L11
Size 337.920(H) x270.336 (V) (43.2cm 17.0")
Pixel pitch 0.264mm( H )x 0.264mm( V )
Viewable angle 140˚ (H) 120˚ (V)
Response time (typ.) 16 ms
Brightness 250
Contrast 400:1
Input
Video Analog
Sync. Type H/V TTL
H-Frequency 30kHz – 83kHz
V-Frequency 50-76Hz
Display Colors Over 16 million Colors
Dot Clock 140MHz
Max. Resolution 1280 x 1024
Plug & Play VESA DDC2B
TM
Power Consumption
ON Mode
≤
37W
Sleep Mode
≤
2W
OFF Mode
≤
1W
Power Source 90~265VAC,47~63Hz
Environmental
Considerations
Operating Temp: 5°C to 35°C
Storage Temp.: -20°C to 60°C
Operating Humidity : 20% to 80%
Main Dimensions
Unpackaged(W*H*D) 379.5mm*390.6mm*203.9mm
Packaged(W*H*D) 454mm*175mm*454mm
Weight (N. W.)
Packaged 6.5Kg Unit
Unpackaged 4.5Kg Unit

HP VS17E Specifications

General

Brand	HP
Model	VS17E
Category	Monitor
Language	English
