HP xw4600 Quickspecs

User Programmable
Modes
Yes, 15
Anti-Glare Yes
Anti-Static Yes
AssetControl Yes (accessible on HP Compaq Business
Desktops featuring Intelligent Manageability)
Default Color
Temperature
Yes (6500k, 9300k, SRGB, Custom User)
On Screen Display
(OSD) Controls
Buttons or Switches Power on/off; 3-button OSD; second level OSD
buttons include dual-input switch, dedicated
auto adjust switch
Languages English, Spanish, French, German,
Netherlands, Italian, Japanese, Simplified
Chinese
User Controls Size and Positioning
Contrast
Brightness
Clock, Clock Phase
Selectable Color Temperature
Serial Number
Mode Displayed
Sleep Timer
Input Selection
Factory Reset
Power Power Supply Auto-ranging, 90 to 265 VAC; internal power
supply
Input Power 100 ~ 240 VAC
Nominal Current 1.5 A maximum
Frequency 50 ~ 60 Hz
Typical Power
Consumption
< 35 watts
Maximum < 55 watts
Power Saving < 2 watts
Off Mode 0 watts (when master power switch is in the off
position)
Power Cable Length 74.8 in (1.9 m); non-captive
Mechanical Dimensions
(H x W x D)
Unpacked with stand 14.85 min to 18.79
max x 15.9 x 8.78
inches (37.72 min to
47.72 max x 40.39 x
22.29 cm)
Base Area
(Footprint D x W)
8.78 x 11.88 inches
(22.29 x 30.18 cm)
Panel only (without
stand) (H x W x D)
12.96 x 15.9 x 2.4
inches (32.91 x 40.39
x 6.1 cm)
Weight Unpacked with stand 15.6 lbs (7.06 kg)
Unpacked without
stand
9.26 lbs (4.19 kg)
Packaged 20.5 lbs (9.27 kg)
Bezel Width 12.5 mm left and right, 12.75 mm top and
bottom
QuickSpecs
HP xw4600 Workstation
Technical Specifications - Monitors
DA - 12792 Worldwide QuickSpecs — Version 19 — 9.12.2008 Page 52

HP xw4600 Specifications

General

Tcase	72.4 °C
Bus type	FSB
Stepping	E0
Processor cache	6 MB
Processor cores	2
Processor model	E8400
System bus rate	- GT/s
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo E8000 Series
Processor socket	LGA 775 (Socket T)
Processor codename	Wolfdale
Processing Die size	107 mm²
Processor frequency	3 GHz
Processor cache type	L2
Processor lithography	45 nm
Processor manufacturer	Intel
Processor front side bus	1333 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	65 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	9
Number of Processing Die Transistors	410 M
Audio system	High Definition Audio
Product type	Workstation
Motherboard chipset	Intel® X38 Express
ECC	Yes
Internal memory	2 GB
Memory clock speed	800 MHz
Internal memory type	DDR2-SDRAM
Maximum internal memory	8 GB
Memory layout (slots x size)	2 x 1 GB
HDD speed	7200 RPM
HDD capacity	250 GB
HDD interface	SATA
Optical drive type	DVD-RW
Graphics card	-
Networking features	Gigabit Ethernet (10/100/1000)
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Power supply	475 W
Chassis type	Tower
Country of origin	China
Processor code	SLB9J
Processor ARK ID	33910
Processor package size	37.5 x 37.5 mm
On-board graphics card model	Not available

Weight and Dimensions

Depth	456 mm
Width	168 mm
Height	450 mm
Weight	19000 g
