HP xw4600 Quickspecs

Tilt Range -4 degrees to +30 degrees
Swivel Range ± 45 degrees horizontal swivel
Height Adjustable Yes (4 in/100mm adjustment range)
Pivot Rotation Yes, 90 degrees
Base Ships attached and is removable
Environmental Temperature –
Operating
41° to 95° F (5° to 35° C)
Temperature – Non-
operating
-4° to 140° F (-20° to 60° C)
Humidity – Operating 20% to 80%
Humidity – Non-
operating
5% to 95%
Altitude – Operating 0 to 12,000 ft (0 to 3,658 m)
Altitude – Non-
operating
0 to 40,000 ft (0 to 12,192 m)
Environmental Data Eco-Label
Certifications and
Declarations
This product has received or is in the process
of being certified to the following approvals and
may be labeled with one or more of these
marks:
US Energy Star
CECP
Energy
Consumption
(in accordance
with US Energy
Star test
method)
AC Input
Voltage at 100
VAC +/- 5 VAC,
50 Hz +/- 3 Hz
AC Input
Voltage at 115
VAC +/- 5 VAC,
60 Hz +/- 3 Hz
AC Input
Voltage at 230
VAC +/- 5 VAC,
50 Hz +/- 3 Hz
Normal
Operation
35.7 watts 35.6 watts 35.1 watts
Sleep 1.08 watts 1.14watts 1.23 watts
Off 0.93 watts 0.94 watts 0.92 watts
Heat
Dissipation*
100 VAC, 50 Hz 115 VAC, 60 Hz 230 VAC, 50 Hz
Normal
Operation
121.7 BTU/hr 121.4 BTU/hr 119.7 BTU/hr
Sleep 3.68 BTU/hr 3.89 BTU/hr 4.19 BTU/hr
Off 3.17 BTU/hr 3.21 BTU/hr 3.14 BTU/hr
*Heat dissipation is calculated based on the measured watts, assuming
the service level is attained for one hour.
Longevity and
Upgrading
Upgradeability features contained in the
product include:
One upstream and four downstream USB ports
Ergonomics The monitor meets the ergonomic requirement
of EN-ISO 13406-2 for flat panel displays.
Additional Information This product is in compliance with the
Restrictions of Hazardous Substances (RoHS)
Directive, 2002/95/EC.
This HP product is designed to comply with the
Waste Electrical and Electronic Equipment
(WEEE) Directive, 2002/96/EC.
QuickSpecs
HP xw4600 Workstation
Technical Specifications - Monitors
DA - 12792 Worldwide QuickSpecs — Version 19 — 9.12.2008 Page 53

HP xw4600 Specifications

General

Tcase	72.4 °C
Bus type	FSB
Stepping	E0
Processor cache	6 MB
Processor cores	2
Processor model	E8400
System bus rate	- GT/s
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo E8000 Series
Processor socket	LGA 775 (Socket T)
Processor codename	Wolfdale
Processing Die size	107 mm²
Processor frequency	3 GHz
Processor cache type	L2
Processor lithography	45 nm
Processor manufacturer	Intel
Processor front side bus	1333 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	65 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	9
Number of Processing Die Transistors	410 M
Audio system	High Definition Audio
Product type	Workstation
Motherboard chipset	Intel® X38 Express
ECC	Yes
Internal memory	2 GB
Memory clock speed	800 MHz
Internal memory type	DDR2-SDRAM
Maximum internal memory	8 GB
Memory layout (slots x size)	2 x 1 GB
HDD speed	7200 RPM
HDD capacity	250 GB
HDD interface	SATA
Optical drive type	DVD-RW
Graphics card	-
Networking features	Gigabit Ethernet (10/100/1000)
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Power supply	475 W
Chassis type	Tower
Country of origin	China
Processor code	SLB9J
Processor ARK ID	33910
Processor package size	37.5 x 37.5 mm
On-board graphics card model	Not available

Weight and Dimensions

Depth	456 mm
Width	168 mm
Height	450 mm
Weight	19000 g
