HP Z1 G2 Product End-Of-Life Disassembly Instructions

[System Parts]
1) Remove the stand
a) Ready for stand remove
b)take off stand cover
c) Use T15 screw driver to
disassemble the stand screw
d) Take the stand leaving from Chassis
e) stand disassembly finish
2) Remove TOP bezel
a)push left and right side latch
b) Open the top bezel
c) disassembly LVDS cable
d) Pull the antenna aux cable out of
PCIe short card
e) Pull the antenna main cable out of
PCIe short card
EL-MF877-00 Page 3
Template Revision B
PSG instructions for this template are available at EL-MF877-01
