HP Z1 G2 - Page 4

h)Pull the connector out of PCA
i) Use T15 screw driver to
disassemble the screw
j) Use T15 screw driver to disassemble
the screw
k) Use T15 screw driver to disassemble
the screw
l) remove Front bezel
m) disassembly finish
3)remove memory FAN
a)Push memory latch.
Then, pull up the memory fan
b) disassembly finish
