HP Z1 G2 - Page 5

4) Remove the HDD
a) Ready for HDD disassembly
b)push HDD handle
pull up the HDD carrier
Pull HDD out of carrier latch
Remove connector
Disassembly SATA connector from
MB
c) Use T15 screw driver to
disassemble the screw
Remove sensor from clip
c) Use T8 screw driver to
disassemble the screw
b) disassembly finish
