HP Z1 Specification

Environmental
Requirements
Temperature Operating: 40° to 95° F (5° to 35° C)
Non-operating: -40° to 140° F (-40° to 60° C)
Humidity Operating: 8% to 85% RH, non-condensing
Non-operating: 8% to 90% RH, non-condensing
Maximum Altitude Operating: 10,000 feet (3,000 m)
Non-operating: 30,000 feet (9,100 m)
Dynamic (new) Shock
Operating: ½-sine: 40g, 2-3ms (~62 cm/sec)
Non-operating:
½-sine: 160 cm/s, 2-3ms (~105g)
square: 422 cm/s, 20g
Vibration
Operating random: 0.5g (rms), 5-300 Hz, up to 0.0025 g²/Hz
Non-operating random: 2.0g (rms), 5-500 Hz, up to 0.0150 g²/Hz
Values represent individual shock events and do not indicate repetitive shock
events. Values do not indicate continuous vibration.
Cooling Above 5,000 ft (1524 m) altitude, maximum operating temperature is de-
rated by 1.8° F (1° C) per 1,000 ft (305 m) elevation increase
Physical Security and Serviceability
Access Panel Tool-less
Includes system board and memory information
Expansion Cards MXM graphics assembly is tool-less.
MiniPCIe cards are screw-in.
Processor Socket Tool-less, except for the processor heatsink.
Green User Touch Points Yes, on tool-free internal chassis mechanisms
Color-coordinated Cables
and Connectors
Yes
Memory Tool-less
System Board Screw-In for motherboard, Rear IO and Side IO boards.
Dual Color Power and HD
LED on Side of Computer
Yes
Configuration Record SW Yes
Over-Temp Warning on
Screen
Yes
Restore CD/DVD Set Restores the computer to its original factory shipping operating system. Orderable with the workstation,
or available from Support.
Dual Function Side Power
Switch
Causes a fail-safe power off when held for 4 seconds
Cable Lock Support Yes, Kensington Cable Lock (optional): Locks side cover and secures chassis from theft
3mm x 7mm slot at rear of system
QuickSpecs
HP Z1 Workstation
System Technical Specifications
DA - 14263 North America — Version 21 — October 4, 2013 Page 19

HP Z1 Specifications

General

Tcase	72.6 °C
Bus type	DMI
Stepping	D2
FSB Parity	No
Processor cache	8 MB
Processor cores	4
Processor model	E3-1245
System bus rate	5 GT/s
Processor series	Intel Xeon E3-1200
Processor socket	LGA 1155 (Socket H2)
Processor threads	8
Processor codename	Sandy Bridge
Processor frequency	3.3 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3.7 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	95 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	33
Maximum number of PCI Express lanes	20
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	1066, 1333 MHz
Memory bandwidth supported by processor (max)	21 GB/s
Maximum internal memory supported by processor	32 GB
Audio system	HD
Product type	Workstation
Motherboard chipset	Intel® C206
Memory slots	4x DIMM
Internal memory	4 GB
Memory channels	Dual-channel
Memory clock speed	1600 MHz
Memory layout (slots x size)	- GB
Resolution	2560 x 1440 pixels
Graphics card	Quadro 500M
Networking features	Gigabit Ethernet (10/100/1000)
Wireless technology	802.11 a/g/n
Graphics card family	NVIDIA
Maximum storage capacity	2 TB
HDD speed	7200 RPM
RAID levels	0, 1
HDD capacity	1000 GB
HDD interface	SATA
Optical drive type	DVD Super Multi
Maximum graphics card memory	1.024 GB
On-board graphics card model	Intel® HD Graphics P3000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	850 MHz
On-board graphics card dynamic frequency (max)	1350 MHz
Number of displays supported (on-board graphics)	2
Display diagonal	27 \
Display number of colors	1.073 billion colors
Modem (RJ-11) ports	0
USB 2.0 ports quantity	7
Bundled software	Roxio Easy Media Creator; Intervideo WinDVD
Operating system installed	Windows 7 Professional
Power supply	400 W
Power supply input voltage	100 - 240 V
Power supply input frequency	50 - 60 Hz
Certification	Energy Star
Product color	Black
Country of origin	China
Processor code	SR00L
Processor ARK ID	52274
Processor package size	37.5 x 37.5 mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	419.1 mm
Width	660.4 mm
Height	584.2 mm
Weight	213.2 g
