HP Z1 Specification

Solenoid Lock and Hood
Sensor
No, Solenoid Lock
Yes, Hood Sensor
The Sensor Kit detects when the access panel has been opened.
Serial, Parallel, USB,
Audio, Network,
Enable/Disable Port
Control
Yes, enables or disables USB, audio, and network ports
Removable Media
Write/Boot Control
Yes, prevents ability to boot from removable media on supported devices (and can disable writes to
media)
Power-On Password Yes, prevents an unauthorized person from booting up the workstation.
Setup Password Yes, prevents an unauthorized person from changing the workstation configuration
3.3V Aux Power LED on
System PCA
No
NIC LEDs (integrated)
(Green & Amber)
Yes
CPUs and Heatsinks A T-15 Torx or flat blade screwdriver is needed to remove the CPU heatsink before the CPU can be
removed. CPU removal is tool-less
Power Supply Diagnostic
LED
Yes
Side Power Button Yes, ACPI multi-function
Side Power LED Yes, blue (normal), red (fault)
Side Hard Drive Activity
LED
Yes, green
Side ODD Activity LED Yes, green
Internal Stereo Speakers Yes, Two 4W speakers
System/Emergency ROM
Flash Recovery
Recovers corrupted system BIOS.
Cooling Solutions Air cooled forced convection
Power Supply Fans 40 mm x 40 mm x 20 mm 4-wire PWM (non-serviceable)
CPU Heatsink Fan Yes, Two 80 mm blowers
MXM Heatsink Fan Yes, One 110 mm blower with MXM graphics assembly
System Blower Yes, 110 mm blower
HP Advanced System
Diagnostics Offline
Edition
HP Vision Diagnostics utility must be booted from USB or CD, and enables you to perform testing and to
view critical computer hardware and software configuration information from various sources.
Access Panel Key Lock No
ACPI-Ready Hardware Advanced Configuration and Power Management Interface (ACPI).
Allows the system to wake from a low power mode
Controls system power consumption, making it possible to place individual cards and peripherals in
a low-power or powered-off state without affecting other elements of the system
QuickSpecs
HP Z1 Workstation
System Technical Specifications
DA - 14263 North America — Version 21 — October 4, 2013 Page 20

HP Z1 Specifications

General

Tcase	72.6 °C
Bus type	DMI
Stepping	D2
FSB Parity	No
Processor cache	8 MB
Processor cores	4
Processor model	E3-1245
System bus rate	5 GT/s
Processor series	Intel Xeon E3-1200
Processor socket	LGA 1155 (Socket H2)
Processor threads	8
Processor codename	Sandy Bridge
Processor frequency	3.3 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3.7 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	95 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	33
Maximum number of PCI Express lanes	20
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	1066, 1333 MHz
Memory bandwidth supported by processor (max)	21 GB/s
Maximum internal memory supported by processor	32 GB
Audio system	HD
Product type	Workstation
Motherboard chipset	Intel® C206
Memory slots	4x DIMM
Internal memory	4 GB
Memory channels	Dual-channel
Memory clock speed	1600 MHz
Memory layout (slots x size)	- GB
Resolution	2560 x 1440 pixels
Graphics card	Quadro 500M
Networking features	Gigabit Ethernet (10/100/1000)
Wireless technology	802.11 a/g/n
Graphics card family	NVIDIA
Maximum storage capacity	2 TB
HDD speed	7200 RPM
RAID levels	0, 1
HDD capacity	1000 GB
HDD interface	SATA
Optical drive type	DVD Super Multi
Maximum graphics card memory	1.024 GB
On-board graphics card model	Intel® HD Graphics P3000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	850 MHz
On-board graphics card dynamic frequency (max)	1350 MHz
Number of displays supported (on-board graphics)	2
Display diagonal	27 \
Display number of colors	1.073 billion colors
Modem (RJ-11) ports	0
USB 2.0 ports quantity	7
Bundled software	Roxio Easy Media Creator; Intervideo WinDVD
Operating system installed	Windows 7 Professional
Power supply	400 W
Power supply input voltage	100 - 240 V
Power supply input frequency	50 - 60 Hz
Certification	Energy Star
Product color	Black
Country of origin	China
Processor code	SR00L
Processor ARK ID	52274
Processor package size	37.5 x 37.5 mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	419.1 mm
Width	660.4 mm
Height	584.2 mm
Weight	213.2 g
