HP Z1 Specification

Trusted Platform Module
Chip with optional
ProtectTools Software
Yes
Integrated Chassis
Handles
Yes, One on top-rear of system
Power Supply Tool-less
miniPCIe Card Retention Yes
Flash ROM Yes
Diagnostic Power Switch
LED on board
No
Clear Password Jumper Yes
Clear CMOS Button Yes
CMOS Battery Holder Yes
DIMM Connectors Yes
HP ProtectTools Security
Manager
Yes - Not supported on Linux
BIOS
BIOS 32-bit Services Standard BIOS 32-bit Service Directory Proposal v0.4
ATAPI ATAPI Removable Media Device BIOS Specification Version 1.0.
BBS BIOS Boot Specification v1.01.
WMI Support WMI is Microsoft's implementation of Web-Based Enterprise Management (WBEM) for Windows. WMI is
fully compliant with the Distributed Management Task Force (DMTF) Common Information Model (CIM) and
WBEM specifications.
BIOS Boot Spec 1.01+ Provides more control over how and from what devices the workstation will boot.
BIOS Power On Users can define a specific date and time for the system to power on.
ROM Based Computer
Setup Utility (F10)
Review and customize system configuration settings controlled by the BIOS.
System/Emergency ROM
Flash Recovery with Video
Recovers system BIOS in corrupted Flash ROM.
Replicated Setup Saves BIOS settings to USB flash device in human readable file. Repset.exe utility can then replicate these
settings on machines being deployed without entering Computer Configuration Utility (F10 Setup).
SMBIOS System Management BIOS 2.7.1, for system management information
Boot Control Disables the ability to boot from removable media on supported devices.
Memory Change Alert Alerts management console if memory is removed or changed.
Thermal Alert Monitors the temperature state within the chassis. Three modes:
NORMAL - normal temperature ranges.
ALERTED - excessive temperatures are detected. Raises a flag so action can be taken to avoid
shutdown or provide for a smoother system shutdown.
SHUTDOWN - excessive temperatures are encountered. Automatically shuts down the computer
without warning before hardware component damage occurs.
QuickSpecs
HP Z1 Workstation
System Technical Specifications
DA - 14263 North America — Version 21 — October 4, 2013 Page 21

HP Z1 Specifications

General

Tcase	72.6 °C
Bus type	DMI
Stepping	D2
FSB Parity	No
Processor cache	8 MB
Processor cores	4
Processor model	E3-1245
System bus rate	5 GT/s
Processor series	Intel Xeon E3-1200
Processor socket	LGA 1155 (Socket H2)
Processor threads	8
Processor codename	Sandy Bridge
Processor frequency	3.3 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3.7 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	95 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	33
Maximum number of PCI Express lanes	20
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	1066, 1333 MHz
Memory bandwidth supported by processor (max)	21 GB/s
Maximum internal memory supported by processor	32 GB
Audio system	HD
Product type	Workstation
Motherboard chipset	Intel® C206
Memory slots	4x DIMM
Internal memory	4 GB
Memory channels	Dual-channel
Memory clock speed	1600 MHz
Memory layout (slots x size)	- GB
Resolution	2560 x 1440 pixels
Graphics card	Quadro 500M
Networking features	Gigabit Ethernet (10/100/1000)
Wireless technology	802.11 a/g/n
Graphics card family	NVIDIA
Maximum storage capacity	2 TB
HDD speed	7200 RPM
RAID levels	0, 1
HDD capacity	1000 GB
HDD interface	SATA
Optical drive type	DVD Super Multi
Maximum graphics card memory	1.024 GB
On-board graphics card model	Intel® HD Graphics P3000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	850 MHz
On-board graphics card dynamic frequency (max)	1350 MHz
Number of displays supported (on-board graphics)	2
Display diagonal	27 \
Display number of colors	1.073 billion colors
Modem (RJ-11) ports	0
USB 2.0 ports quantity	7
Bundled software	Roxio Easy Media Creator; Intervideo WinDVD
Operating system installed	Windows 7 Professional
Power supply	400 W
Power supply input voltage	100 - 240 V
Power supply input frequency	50 - 60 Hz
Certification	Energy Star
Product color	Black
Country of origin	China
Processor code	SR00L
Processor ARK ID	52274
Processor package size	37.5 x 37.5 mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	419.1 mm
Width	660.4 mm
Height	584.2 mm
Weight	213.2 g
