HP Z1 Specification

Remote ROM Flash Provides secure, fail-safe ROM image management from a central network console.
ACPI (Advanced
Configuration and Power
Management Interface)
Allows the system to enter and resume from low power modes (sleep states).
Enables an operating system to control system power consumption based on the dynamic workload.
Makes it possible to place individual cards and peripherals in a low-power or powered-off state without
affecting other elements of the system.
Ownership Tag A user-defined string stored in non-volatile memory that is displayed in the BIOS splash screen.
Remote Wakeup/
Remote Shutdown
System administrators can power on, restart, and power off a client computer from a remote location.
Instantly Available PC
(Suspend to RAM - ACPI
sleep state S3)
Allows for very low power consumption with quick resume time
Remote System
Installation via F12 (PXE
2.1) (Remote Boot from
Server)
Allows a new or existing system to boot over the network and download software, including the operating
system.
ROM revision levels Reports the system BIOS revision level in Computer Configuration Utility (F10 Setup). Version is available
through an industry standard interface (SMBIOS) so that management SW applications can use and report
this information.
System board revision
level
Allows management SW to read revision level of the system board.
Revision level is digitally encoded into the HW and cannot be modified.
Start-up Diagnostics
(Power-on Self-Test)
Assesses system health at boot time with selectable levels of testing.
Auto Setup when new
hardware installed
System automatically detects addition of new hardware.
Keyboard-less Operation The system can be booted without a keyboard
Localized ROM Setup Common BIOS image supports System Configuration Utility (F10 Setup) menus in 12 languages with local
keyboard mappings.
Asset Tag The user or MIS to set a unique tag string in non-volatile memory.
Per-slot Control Allows I/O slot parameters (option ROM enable/disable, bus latency) to be configured individually.
Adaptive Cooling Control parameters are set according to detected hardware configuration for optimal acoustics.
Pre-boot Diagnostics (Pre-video) critical errors are reported via beeps and blinks on the power LED.
Intel® Active Management
Technology (AMT)
AMT 7.0; Allows workstation status to be monitored on a remote console
Industry Standard
Specification Support
UEFI Specification
Revision
2.3.1
ACPI Advanced Configuration and Power Management Interface, Version 1.0
ASF No
ATA (IDE) AT Attachment 6 with Packet Interface (ATA/ATAPI-6), Revision 3b
CD Boot "El Torito" Bootable CD-ROM Format Specification Version 1.0
EDD Enhanced Disk Drive Specification Version 1.1
BIOS Enhanced Disk Drive Specification Version 3.0
QuickSpecs
HP Z1 Workstation
System Technical Specifications
DA - 14263 North America — Version 21 — October 4, 2013 Page 22

HP Z1 Specifications

General

Tcase	72.6 °C
Bus type	DMI
Stepping	D2
FSB Parity	No
Processor cache	8 MB
Processor cores	4
Processor model	E3-1245
System bus rate	5 GT/s
Processor series	Intel Xeon E3-1200
Processor socket	LGA 1155 (Socket H2)
Processor threads	8
Processor codename	Sandy Bridge
Processor frequency	3.3 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3.7 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	95 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	33
Maximum number of PCI Express lanes	20
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	1066, 1333 MHz
Memory bandwidth supported by processor (max)	21 GB/s
Maximum internal memory supported by processor	32 GB
Audio system	HD
Product type	Workstation
Motherboard chipset	Intel® C206
Memory slots	4x DIMM
Internal memory	4 GB
Memory channels	Dual-channel
Memory clock speed	1600 MHz
Memory layout (slots x size)	- GB
Resolution	2560 x 1440 pixels
Graphics card	Quadro 500M
Networking features	Gigabit Ethernet (10/100/1000)
Wireless technology	802.11 a/g/n
Graphics card family	NVIDIA
Maximum storage capacity	2 TB
HDD speed	7200 RPM
RAID levels	0, 1
HDD capacity	1000 GB
HDD interface	SATA
Optical drive type	DVD Super Multi
Maximum graphics card memory	1.024 GB
On-board graphics card model	Intel® HD Graphics P3000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	850 MHz
On-board graphics card dynamic frequency (max)	1350 MHz
Number of displays supported (on-board graphics)	2
Display diagonal	27 \
Display number of colors	1.073 billion colors
Modem (RJ-11) ports	0
USB 2.0 ports quantity	7
Bundled software	Roxio Easy Media Creator; Intervideo WinDVD
Operating system installed	Windows 7 Professional
Power supply	400 W
Power supply input voltage	100 - 240 V
Power supply input frequency	50 - 60 Hz
Certification	Energy Star
Product color	Black
Country of origin	China
Processor code	SR00L
Processor ARK ID	52274
Processor package size	37.5 x 37.5 mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	419.1 mm
Width	660.4 mm
Height	584.2 mm
Weight	213.2 g
