HP Z210 SFF

Internal Speaker Yes
System/Emergency ROM
Flash Recovery
Recovers corrupted system BIOS.
Cooling Solutions Air cooled forced convection
Power Supply Fans 92 mm x 92 mm x 25 mm 4-wire PWM (non-serviceable)
CPU Heatsink Fan Not applicable- CPU heatsink is passive.
MXM Heatsink Fan 92 mm x 92mm x 25 mm 4-wire PWM
Memory Heatsink Fan No
HP Vision Diagnostics
Offline Edition
HP Vision Diagnostics utility must be booted from USB or CD, and enables you to perform testing and to
view critical computer hardware and software configuration information from various sources.
Access Panel Key Lock No
ACPI-Ready Hardware Advanced Configuration and Power Management Interface (ACPI).
Allows the system to wake from a low power mode.
Controls system power consumption, making it possible to place individual cards and peripherals in
a low-power or powered-off state without affecting other elements of the system
Trusted Platform Module
Chip with optional
ProtectTools Software
Yes
Integrated Chassis
Handles
No
Power Supply Tool-less
PCI Card Retention Yes, rear (all), middle (none), front (none)
Flash ROM Yes
Diagnostic Power Switch
LED on board
Yes
Clear Password Jumper Yes
Clear CMOS Button Yes
CMOS Battery Holder Yes
DIMM Connectors Yes
HP ProtectTools Security
Manager
Yes - Not supported on Microsoft XP x64 or Linux
BIOS
BIOS 32-bit Services Standard BIOS 32-bit Service Directory Proposal v0.4
PCI 3.0 Support Full BIOS support for PCI Express through industry standard interfaces.
ATAPI ATAPI Removable Media Device BIOS Specification Version 1.0.
BBS BIOS Boot Specification v1.01.
WMI Support WMI is Microsoft's implementation of Web-Based Enterprise Management (WBEM) for Windows. WMI is
fully compliant with the Distributed Management Task Force (DMTF) Common Information Model (CIM) and
WBEM specifications.
QuickSpecs
HP Z210 SFF Workstation
System Technical Specifications
DA - 13873 Worldwide — Version 26 — October 4, 2013 Page 21
