HP Z230 Specification

High End 3D
AMD FirePro W7000 4GB Graphics N Y C2K00AA 1 NO
NVIDIA Quadro K4000 3GB Graphics Y Y C2J94AA 1 NO
Intermixing integrated Intel HD graphics and discrete graphics cards in order to drive more than three
displays can be enabled using the Computer (F10) Setup Utility. However, HP recommends using only
discrete graphics when four or more displays are required to be supported.
Memory Sub-Section Description/Notes
Intel® Xeon E3, Intel Core i3 and Intel Pentium processors can support either ECC or non-ECC memory;
Intel® Core i5/i7 processors only support non-ECC memory.
CTO Support Notes
DDR3-1600 nECC Unbuffered DIMMs CTO
HP 32GB (4x8GB) DDR3-1600 nECC RAM
HP 16GB (2x8GB) DDR3-1600 nECC RAM
HP 16GB (4x4GB) DDR3-1600 nECC RAM
HP 8GB (2x4GB) DDR3-1600 nECC RAM
HP 4GB (1x4GB) DDR3-1600 nECC RAM
DDR3-1600 ECC Unbuffered DIMMs - CTO
HP 32GB (4x8GB) DDR3-1600 ECC RAM
HP 16GB (2x8GB) DDR3-1600 ECC RAM
HP 16GB (4x4GB) DDR3-1600 ECC RAM
HP 8GB (2x4GB) DDR3-1600 ECC RAM
HP 4GB (2x2GB) DDR3-1600 ECC RAM
HP 4GB (1x4GB) DDR3-1600 ECC RAM
Sub-Section Description/Notes
Two channels of DDR3 memory are supported. To realize full performance at least one DIMM must be
inserted into each channel.
AMO Option Kit Part
Number
Support Notes
DDR3-1600 nECC Unbuffered DIMMs AMO
HP 8GB (1x8GB) DDR3-1600 non-ECC RAM B1S54AA
HP 4GB (1x4GB) DDR3-1600 nECC RAM B1S53AA
DDR3-1600 ECC Unbuffered DIMMs - AMO
HP 8GB (1x8GB) DDR3-1600 ECC RAM A2Z50AA
HP 4GB (1x4GB) DDR3-1600 ECC RAM A2Z48AA
HP 2GB (1x2GB) DDR3-1600 ECC RAM A2Z47AA
NOTE: Only unbuffered DDR3 DIMMs are supported.
The CPUs determine the speed at which the memory is clocked. If a 1333 MHz capable CPU is used in the
system, the maximum speed the memory will run at is 1333 MHz regardless of the specified speed of the
memory.
QuickSpecs
HP Z230 Tower Workstation
Supported Components
DA - 14629 Worldwide — Version 13 — February 3, 2014 Page 10

HP Z230 Specifications

General

Product type	Workstation
Motherboard chipset	Intel® C226
ECC	Yes
Memory slots	4x DIMM
Internal memory	4 GB
Memory channels	Dual-channel
Memory clock speed	1600 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	32 GB
Memory layout (slots x size)	1 x 4 GB
Chassis type	Desktop
Product color	Black
Country of origin	China
Placement supported	Vertical
Number of 3.5\" bays	1
Water cooling system	No
HDD speed	7200 RPM
RAID levels	0, 1
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi
Total storage capacity	500 GB
PS/2 ports quantity	2
DisplayPorts quantity	3
Serial ports quantity	-
USB 2.0 ports quantity	6
VGA (D-Sub) ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
Ethernet LAN data rates	10, 100, 1000 Mbit/s
On-board graphics card ID	0x412
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 4600
Maximum on-board graphics card memory	1.74 GB
On-board graphics card base frequency	350 MHz
On-board graphics card DirectX version	11.1
On-board graphics card dynamic frequency (max)	1150 MHz
Power supply	240 W
Tcase	72.72 °C
Bus type	DMI2
Stepping	C0
Processor cache	6 MB
Processor model	i5-4570
System bus rate	5 GT/s
Processor family	Intel® Core™ i5
Processor socket	LGA 1150 (Socket H3)
Processor codename	Haswell
Processor frequency	3.2 GHz
Processor cache type	Smart Cache
Processor lithography	28 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.6 GHz
Processor operating modes	64-bit
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	84 W
Maximum number of PCI Express lanes	16
Memory clock speeds supported by processor	1333, 1600 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Operating system installed	Windows 7 Professional
Scalability	1S
Processor code	SR14E
Processor ARK ID	75043
Intel TSX-NI version	0.00
Processor package size	37.5 x 37.5 mm
Graphics & IMC lithography	22 nm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Thermal solution specification	PCG 2013D
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	384 mm
Width	337 mm
Height	100 mm
Weight	7200 g
