HP Z230

Controller Cards
Factory
Configured
Option
Kit
Option
Kit Part
Number
Support
Notes
HP IEEE 1394b FireWire PCIe Card Y Y NK653AA See Note
1
HP USB 3.0 2x2 Port SuperSpeed PCIe x1 Card N Y QT587AA See Note
2
NOTE 1: For the HP Z230 CMT Workstation the 1394b card is only supported on Slots 3, 4, or 5
NOTE 2: : Four USB 3.0 ports are available integrated on the motherboard (2 front, 2 rear). Integrated USB
3.0 ports are supported under Microsoft Windows 7 or Microsoft Windows 8 operating systems only.
Networking and
Communications Factory
Configured
Option
Kit
Option
Kit Part
Number
Support
Notes
Integrated Intel I217LM PCIe GbE Controller Y N See Notes
1, 2, 3
Intel Ethernet I210-T1 PCIe NIC Y Y E0X95AA See Notes
3, 4
HP X520 10GbE Dual Port Adapter Y Y C3N52AA
HP 10GbE SFP+ SR Transceiver Y Y C3N53AA
Intel 6205 802.11 a/b/g/n PCIe x1 WLAN Card N Y E0X93AA
NOTE 1 : The integrated network connection is required to support Intel vPro Technology.
NOTE 2 : If AMT is enabled network teaming with the integrated LAN port is not possible.
NOTE 3 : "Gigabit" Ethernet indicates compliance with IEEE standard 802.3ab for Gigabit Ethernet, and does
not connote actual operating speed of 1 Gb/sec. For high speed transmission, connection to a Gigabit
Ethernet server and network infrastructure is required.
NOTE 4 : The Intel Ethernet I210-T1 PCIe NIC is supported on the following operating systems:
Microsoft Windows 7 and Windows 8 32-bit and 64-bit versions
Red Hat Enterprise Linux(RHEL)
SLED 11.
Racking and Physical
Security Factory
Configured Option Kit
Option Kit
Part
Number
Support
Notes
HP xw4/Z2/Z4 Depth Adjustable Fixed Rail Rack Kit N Y WH340AA
HP Solenoid Lock and Hood (TWR) Sensor Y Y E0X96AA
HP Business PC Security Lock Kit N Y PV606AA
HP UltraSlim Cable Lock Kit N Y H4D73AA
QuickSpecs
HP Z230 Tower Workstation
Supported Components
DA - 14629 Worldwide — Version 13 — February 3, 2014 Page 12
