HP Z230

Max. resolution supported on DP 1.2 ports: 3840x2160 @60Hz
Network Controller Integrated Ethernet PHY Connection I217LM. Management
capabilities: WOL, PXE 2.1 and AMT 9
External SATA (eSATA) 1 port eSATA capable (SATA 5) with optional eSATA After-
Market Option cable kit.
IDE connector No
Floppy connector No
Serial 1 internal header (requires optional Serial Port Adapter Kit)
2nd Serial No
Parallel 1 internal header (optional Parallel Port Adapter required)
HD Integrated Audio Yes
CD-ROM input (Audio) No
AUX input (Audio) No
IEEE 1394 Connector(s) Rear 2 IEEE 1394b ports (requires optional PCIe 1394b card)
Internal No
USB Connector(s) Front 2 USB 3.0, 1 USB 2.0, 1 USB 2.0 Charging Data Port.
Rear 2 USB 3.0, 4 USB 2.0
Internal 1 USB 3.0 and 3 USB 2.0 ports available as 2 separate 2x10(3.0
x1,2.0 x1) and 2x5(2.0 x2) headers: supports 1 HP Internal USB
Port Kits plus one USB 3.0 Media Card Reader.
HD Integrated Audio Yes
Flash ROM Yes
CPU Fan Header Yes
Chassis Fan Header 1 Rear System Chassis Fan Header, 1 Optional Front Chassis Fan Header
Front Control
Panel/Speaker Header
Yes
CMOS Battery Holder -
Lithium
Yes
Integrated Trusted
Platform Module
Integrated TPM 1.2.
The TPM module disabled where restricted by law, i.e. Russia.
Power Supply Headers Yes
Power Switch, Power LED
& Hard Drive LED Header
Yes
Clear Password Jumper Yes
Keyboard/Mouse USB or PS/2
400W Wide Ranging, Active PFC, 92% Efficient;
(Note: 320W Standard Efficiency wide-ranging, active PFC Power Supply option available in some
countries).
The Z230 Tower 400W PSU Efficiency Report can be found at this link:
http://www.plugloadsolutions.com/psu_reports/HEWLETT-PACKARD%20COMPANY_704427-
001%20(DPS-400AB-19%20A)_400W_ECOS%203496_Report.pdf
QuickSpecs
HP Z230 Tower Workstation
System Technical Specifications
DA - 14629 Worldwide — Version 13 — February 3, 2014 Page 16
