HP Z230 Specification

Windows 8.1 Pro Downgrade to Windows 7 Professional 32-bit (National Academic)
Windows 8.1 Pro Downgrade to Windows 7 Professional 64-bit (National Academic)
HP Installer Kit for Linux [includes drivers for 64-bit OS versions of Red Hat Enterprise Linux 6 and
SUSE Linux Enterprise Desktop (SLED) 11]
SUSE Linux Enterprise Desktop 11 64-bit (90 day license)
Red Hat Enterprise Linux Workstation (1 year paper license available; Preinstall not available)
Supported:
Genuine Windows® 7 Enterprise 32/64
Notes: For detailed OS/hardware support information for Linux, see:
http://www.hp.com/support/linux_hardware_matrix
Name Cores
Clock
Speed
(GHz)
Intel® Turbo
Boost
Technology
1
Cache
(MB)
Memory
Speed
(MHz)
Hyper-
Threading
Integrated
Graphics
Featuring
Intel® vPro™
Technology
TDP
(W)
Intel® Xeon® processor
E3-1280v3
4 3.6 4.0 8 1600 Y N/A Y 80W
Intel® Xeon® processor
E3-1270v3
4 3.5 3.9 8 1600 Y N/A Y 80W
Intel® Xeon® processor
E3-1245v3
4 3.4 3.8 8 1600 Y
Intel HD Graphics
P4600
Y 84W
Intel® Xeon® processor
E3-1240v3
4 3.4 3.8 8 1600 Y N/A Y 80W
Intel® Xeon® processor
E3-1230v3
4 3.3 3.7 8 1600 Y N/A Y 80W
Intel® Xeon® processor
E3-1225v3
4 3.2 3.6 8 1600 N
Intel HD Graphics
P4600
Y 84W
Intel® Core
TM
i7-4771
processor
4 3.5 3.9 8 1600 Y
Intel HD Graphics
4600
Y 84W
Intel® Core
TM
i7-4770
processor
4 3.4 3.9 8 1600 Y
Intel HD Graphics
4600
Y 84W
Intel® Core
TM
i5-4670
processor
4 3.4 3.8 6 1600 N
Intel HD Graphics
4600
Y 84W
Intel® Core
TM
i5-4570
processor
4 3.2 3.6 6 1600 N
Intel HD Graphics
4600
Y 84W
Intel® Core
TM
i3-4330
processor
2 3.5 N/A 4 1600 Y
Intel HD Graphics
4600
N 54W
Intel® Core
TM
i3-4130
processor
2 3.4 N/A 3 1600 Y
Intel HD Graphics
4400
N 54W
Intel® Pentium® G3220
processor
2 3.0 N/A 3 1333 N Intel HD Graphics N 54W
1
The specifications shown in this column represent the maximum turbo frequency with one core active. Turbo boost stepping occurs
in 100MHz increments. Processors that do not have turbo functionality are denoted as N/A.
Available Processor
Disclaimers
Integrated Intel® HD graphics is not supported on the Intel Xeon processor E3-1230v3, E3-1240v3, E3-
1270v3 or E3-1280v3.
Intel® Xeon E3, Intel Core i3 and Intel Pentium processors can support either ECC or non-ECC memory;
Intel® Core i5/i7 processors only support non-ECC memory.
QuickSpecs
HP Z230 Tower Workstation
Overview
DA - 14629 Worldwide — Version 13 — February 3, 2014 Page 3

HP Z230 Specifications

General

Product type	Workstation
Motherboard chipset	Intel® C226
ECC	Yes
Memory slots	4x DIMM
Internal memory	4 GB
Memory channels	Dual-channel
Memory clock speed	1600 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	32 GB
Memory layout (slots x size)	1 x 4 GB
Chassis type	Desktop
Product color	Black
Country of origin	China
Placement supported	Vertical
Number of 3.5\" bays	1
Water cooling system	No
HDD speed	7200 RPM
RAID levels	0, 1
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi
Total storage capacity	500 GB
PS/2 ports quantity	2
DisplayPorts quantity	3
Serial ports quantity	-
USB 2.0 ports quantity	6
VGA (D-Sub) ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
Ethernet LAN data rates	10, 100, 1000 Mbit/s
On-board graphics card ID	0x412
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 4600
Maximum on-board graphics card memory	1.74 GB
On-board graphics card base frequency	350 MHz
On-board graphics card DirectX version	11.1
On-board graphics card dynamic frequency (max)	1150 MHz
Power supply	240 W
Tcase	72.72 °C
Bus type	DMI2
Stepping	C0
Processor cache	6 MB
Processor model	i5-4570
System bus rate	5 GT/s
Processor family	Intel® Core™ i5
Processor socket	LGA 1150 (Socket H3)
Processor codename	Haswell
Processor frequency	3.2 GHz
Processor cache type	Smart Cache
Processor lithography	28 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.6 GHz
Processor operating modes	64-bit
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	84 W
Maximum number of PCI Express lanes	16
Memory clock speeds supported by processor	1333, 1600 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Operating system installed	Windows 7 Professional
Scalability	1S
Processor code	SR14E
Processor ARK ID	75043
Intel TSX-NI version	0.00
Processor package size	37.5 x 37.5 mm
Graphics & IMC lithography	22 nm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Thermal solution specification	PCG 2013D
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	384 mm
Width	337 mm
Height	100 mm
Weight	7200 g
