HP Z620 Specification

operating system, device drivers, and applications enabled for Intel® 64 architecture. Processor will not
operate (including 32-bit operation) without an Intel® 64 architecture-enabled BIOS. Performance will vary
depending on your hardware and software configurations. See: http://www.intel.com/info/em64t for more
information.
Additional Details Intel® Sandy Bridge Architecture
Intel® C602 Chipset
Intel® Xeon® processor E5-2600 product family
Intel® Xeon® processor E5-2600 v2 product family
Intel® Xeon® processor E5-1600 product family
Intel® Xeon® processor E5-1600 v2 product family
(Sandy Bridge, Socket R)
Up to 8.0GT/s QPI support with two QPI links between processors
4-channel per processor 1066/1333/1600/1866 MHz DDR3 memory* subsystem
Up to 192 GB Memory capacity with 12 DIMM slots and 16 GB DIMMs (with two processors installed)
PCI Express I/O and dual PCIe x16 Gen3 graphics support
Dual Integrated Intel Gigabit LAN on Motherboard (LOM)
2 channels of Serial ATA (SATA) 6.0 Gb/s and 8 channels of SATA 3.0 Gb/s natively supported
internally
SATA RAID 0, 1, 5, and 10 support standard on motherboard
SAS RAID 0, 1, and 10 supported using the LSI 9212-4i 6Gb/s controller
SATA optical drives
High Definition integrated audio with internal speaker
800W 90% efficient power supply
ENERGY STAR® qualification and energy-saving features available on selected configurations (Not
supported by Linux)
Protected by HP Services, including a 3 years parts, 3 years labor, and 3 years onsite service (3/3/3)
standard warranty. Terms and conditions vary by country. Certain restrictions and exclusions apply.
*Each processor supports up to 4 channels of DDR3 memory. To realize full performance at least 1 DIMM
must be inserted into each channel. To get full 8 channel support, 2 processors MUST be installed.
Form Factor 4U Rackable Minitower
Color Brushed aluminum & black
I/O Expansion Slots Slot 1 (top):
PCI Express Gen2 x4(1)*
Full-height, Half-length
(not available when 2nd CPU/Memory Module is installed)
Slot 2:
PCI Express Gen3 x16
Full-height, Full-length (with extender)
Slot 3:
PCI Express Gen2 x8(4)* with open-ended connector**
Full-height, Full-length (with extender)
Slot 4:
PCI Express Gen3 x8 with open-ended connector**
Full-height, Full-length (with extender)
Slot 5:
PCI Express Gen3 x16
QuickSpecs
HP Z620 Workstation
Overview
DA - 14262 North America — Version 35 — December 12, 2013 Page 6

HP Z620 Specifications

General

Tcase	77.4 °C
Bus type	QPI
Stepping	C2
FSB Parity	No
Processor cache	15 MB
Processor cores	6
Processor model	E5-2630
System bus rate	7.2 GT/s
Processor series	Intel Xeon E5-2600
Processor socket	LGA 2011 (Socket R)
Processor threads	12
Processor codename	Sandy Bridge EP
Number of QPI links	2
Processor frequency	2.3 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	2.8 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
PCI Express configurations	x4, x8, x16
Thermal Design Power (TDP)	95 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	28
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	800, 1066, 1333, 1600 MHz
Memory bandwidth supported by processor (max)	42.6 GB/s
Maximum internal memory supported by processor	750 GB
Audio system	-
Product type	Workstation
Motherboard chipset	Intel® C602
Internal memory	4 GB
Memory channels	Quad-channel
Memory clock speed	1600 MHz
Maximum internal memory	- GB
Memory layout (slots x size)	2 x 2 GB
HDD speed	7200 RPM
HDD capacity	500 GB
HDD interface	SATA
Optical drive type	DVD Super Multi
Graphics card	FirePro V5900
External drive bays	2 x 5.25\
Internal drive bays	3 x 3.5\
Graphics card family	AMD
Serial ports quantity	0
USB 2.0 ports quantity	5
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
Chassis type	Tower
Country of origin	China
Operating system installed	Windows 7 Professional
Power supply	800 W
Maximum graphics card memory	2.048 GB
Scalability	2S
Processor ARK ID	64593
Processor package size	52.5 x 45.0 mm
Supported instruction sets	AVX
Intel® Turbo Boost Technology	1.0
Physical Address Extension (PAE)	46 bit
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	0.00

Weight and Dimensions

Depth	464.8 mm
Width	171.5 mm
Height	444.5 mm
Weight	15500 g
