Full-height, Full-length (with extender)
Slot 6:
PCI 32bit/33MHz
Full-height, Full-length (with extender)
* x<number> = number of lanes or size of the physical/mechanical connector.
(number) = number of lanes supported electrically. Typically communicated as x# mechanical,
x(#)electrical.
** open-ended connector allow a greater bandwidth (e.g. x16) card to be installed physically into a lower
bandwidth connector/slot.
Mass Storage Bays
(see
Storage section for more
details)
Total bays = 5
Internal Bays
3 internal 3.5" bays (with acoustic dampening rail assemblies pre-installed)
External Bays
2 external 5.25" bays
(4th HDD occupies one external bay)
Front I/O
2 USB 3.0, 1 USB 2.0, 1 Headphone, 1 Microphone, 1 IEEE 1394a
Rear I/O
2 USB 3.0, 4 USB 2.0, 2 RJ-45 integrated Gigabit LAN, 2 PS/2, 1 Audio Line-In, 1 Audio Line-Out, 1
Microphone
Serial supported with optional connector on PCI bracket cabled to system board connector
Internal USB
6 USB 2.0 ports available by three separate 2x5 headers. Each 2x5 header supports either one HP Internal
USB Port Kit (EM165AA) or one 22-in-1 Media Card Reader.
Chassis Dimensions
(H x W
x D)
44.45 x 17.15 x 46.48 cm (17.5 x 6.75 x 18.3 in)
Rack utilization: 4U
System Weight
Actual weight depends upon configuration
Minimum config: 15.5 kg (34.2 lb)
Typical config: 17.9 kg (39.4 lb)
Maximum config: 22.6 kg (49.9 lb)
Temperature
Operating:
5° to 35° C (40° to 95° F)
Non-operating
-40° to 60° C (-40° to 140° F)
Humidity
Operating:
8% to 85% relative humidity, non-condensing
Non-operating
8% to 90% relative humidity, non-condensing
Maximum Altitude
(non-
pressurized)
Operating:
3,048m (10,000ft)
Non-operating
9,144m (30,000ft)
Power Supply
Tool-free 800W 90% Efficient wide-ranging, active Power Factor Correction
The Power Supply Efficiency Report for this product may be found at this link: TBD
Interfaces Supported
10-channel SATA Interface (2 @ 6.0 Gb/s and 8 @ 3.0 Gb/s). 6 channels are eSATA configurable (2 @ 6 Gb/s,
4 @ 3 Gb/s) for use with eSATA CTO/AMO Kit.
SAS interface supported
USB 3.0, USB 2.0, IEEE 1394a interface
Hard Drive Controllers
Supported
SATA and SAS controllers
Backup Devices
For a complete listing of compatible DAT tape drives, LTO tape drives and RDX Removable Disk Backup
System offerings, please visit
http://www.hp.com/go/connect
Workstation ISV
Certifications
See the latest list of certifications at
http://www.hp.com/united-states/campaigns/workstations/partnerships.html
QuickSpecs
HP Z620 Workstation
Overview
DA - 14262 North America — Version 35 — December 12, 2013
Page 7
