HP Z6800 - Technical Specifications and Ordering Information; Technical Specifications; Ordering Information; Service and Support

Data sheet | HP Designjet Z6800 Photo Production Printer
Technical specications Ordering information
Print Maximum print speed
9
140 m²/hr (1500 ft²/hr) on plain media
Color images
10
Best: 3.2 min/page on A1/D or up to 13.1 m²/hr
(141 ft²/hr) on glossy media
Normal: 2.1 min/page on A1/D or up to 19.7 m²/hr
(212 ft²/hr) on glossy media
Print resolution Up to 2400 x 1200 optimized dpi
Margins 5 x 5 x 5 x 5 mm (0.2 x 0.2 x 0.2 x 0.2 in)
Ink types Pigment-based
Technology HP Thermal Inkjet
Ink cartridges 8 (Chromatic red, magenta, yellow, light cyan, light gray,
light magenta, matte black, photo black)
Line accuracy +/- 0.1%8
11
Minimum line width 0.02 mm (0.0008 in) (HP-GL/2 addressable)
Guaranteed minimum line
width
0.067 mm (0.0026 in) (ISO/IEC 13660:2001(E))
12
Image quality Color accuracy Median < 1.25 dE2000, 95% of colours < 2.75 dE2000
13
Short term color stability < 1 dE2000 less than 5 minutes
14
Long term print-to-print
repeatability
Average < 0.5 dE2000, 95% of colours < 1.25 dE2000
14
Maximum optical density 4.5 L* min/2.31 D
15
Media Handling Roll feed, automatic cutter, take-up reel
Media types Bond and coated paper, technical paper, lm, photographic
paper, proong paper, backlit, self-adhesive, banner and
sign, fabric, ne art printing material
Size 279 to 1524-mm (11 to 60-in) rolls
Thickness Up to 0.56 mm (22 mil)
Applications Posters, Banners, Mockups, Photos, Digital ne art, Proofs, Displays, POP/POS, Light
boxes – lm, Exhibition, Event graphics
Memory 64 GB (virtual)
16
, 320 GB hard disk
Connectivity Interfaces (standard) Gigabit Ethernet (1000Base-T), EIO Jetdirect accessory
slot
Print languages (standard) HP-GL/2, HP-RTL, CALS G4
Print languages (optional) Adobe PostScript 3, Adobe PDF 1.7, TIFF, JPEG
Printing paths Printer driver, HP Embedded Web Server
Drivers (included) HP-GL/2, HP-RTL drivers for Windows; PostScript
Windows and Mac drivers with optional PostScript/PDF
Upgrade Kit
Dimensions
(w x d x h)
Printer 2430 x 690 x 1370 mm (95.7 x 27.2 x 53.9 in)
Shipping 2700 x 750 x 1200 mm (106.3 x 29.5 x 47.2 in)
Weight Printer 190 kg (419 lb)
Shipping 252 kg (555.6 lb)
What’s in the
box
HP Designjet Z6800 Photo Production Printer, spindle, printheads, introductory ink
cartridges, maintenance cartridge, printer stand, take-up reel, 3-in spindle adapter
kit, quick reference guide, setup poster, startup software, power cord
Environmental
ranges
Operating temp. -20 to 55�C (-4 to 131�F)
Storage temp. -20 to 55�C (-4 to 131�F)
Operating humidity 20 to 80% RH
Acoustic Sound pressure 53 dB(A) (printing); 39 dB(A) (ready); 39 dB(A) (sleep)
Sound power 7.0 B(A) (printing); 5.5 B(A) (ready); 5.5 B(A) (sleep)
Power Consumption 270 watts (printing); < 48 watts (ready); < 5.3 watts
(sleep); < 0.3 watts (o)
Requirements Input voltage (auto ranging): 100 to 127 VAC (+/- 10%), 5 A;
220 to 240 VAC (+/- 10%), 3 A; 50/60 Hz (+/- 3 Hz)
Certication Safety USA and Canada (CSA certied), EU (LVD and EN 60950-1
compliant), Russia (GOST), Singapore (PSB), China (CCC),
Argentina (IRAM), Mexico (NYCE), Korea (KC)
Electromagnetic Compliant with Class A requirements, including: USA (FCC
rules), Canada (ICES), EU (EMC Directive), Australia (ACMA),
New Zealand (RSM), China (CCC), Japan (VCCI), Korea (MSIP)
Environmental ENERGY STAR, WEEE, RoHS (EU, China, Korea, India),
REACH, EPEAT Bronze
Warranty One-year limited hardware warranty
Product F2S72A HP Designjet Z6800 60-in Photo Production Printer
Accessories G6H51A HP Designjet HD Pro Scanner
CQ745B HP Designjet PostScript/PDF Upgrade Kit
CQ754A HP Designjet 60-in Spindle
J8025A HP Jetdirect 640n Print Server
Q6714A HP Designjet 60-in Media Bin
Q6715A HP Designjet User Maintenance Kit
Original HP
printheads
CE017A HP 771 Matte Black and Chromatic Red Designjet Printhead
CE018A HP 771 Magenta and Yellow Designjet Printhead
CE019A HP 771 Light Magenta and Light Cyan Designjet Printhead
CE020A HP 771 Photo Black and Light Gray Designjet Printhead
Original HP ink
cartridges and
maintenance
supplies
B6Y15A HP 771A 775-ml Matte Black Designjet Ink Cartridge
B6Y16A HP 771A 775-ml Chromatic Red Designjet Ink Cartridge
B6Y17A HP 771A 775-ml Magenta Designjet Ink Cartridge
B6Y18A HP 771A 775-ml Yellow Designjet Ink Cartridge
B6Y19A HP771A 775-ml Light Magenta Designjet Ink Cartridge
B6Y20A HP771A 775-ml Light Cyan Designjet Ink Cartridge
B6Y21A HP771A 775-ml Photo Black Designjet Ink Cartridge
B6Y22A HP771A 775-ml Light Gray Designjet Ink Cartridge
B6Y39A HP 771A 3-pack 775-ml Matte Black Designjet Ink Cartridge
B6Y40A HP 771A 3-pack 775-ml Chromatic Red Designjet Ink Cartridge
B6Y41A HP 771A 3-pack 775-ml Magenta Designjet Ink Cartridge
B6Y42A HP 771A 3-pack 775-ml Yellow Designjet Ink Cartridge
B6Y43A HP 771A 3-pack 775-ml Light Magenta Designjet Ink Cartridge
B6Y44A HP 771A 3-pack 775-ml Light Cyan Designjet Ink Cartridge
B6Y45A HP 771A 3-pack 775-ml Photo Black Designjet Ink Cartridge
B6Y46A HP 771A 3-pack 775-ml Light Gray Designjet Ink Cartridge
C1Q21A HP 773A 775-ml Matte Black Designjet Ink Cartridge
17
C1Q22A HP 773A 775-ml Chromatic Red Designjet Ink Cartridge
17
C1Q23A HP 773A 775-ml Magenta Designjet Ink Cartridge
17
C1Q24A HP 773A 775-ml Yellow Designjet Ink Cartridge
17
C1Q25A HP 773A 775-ml Light Magenta Designjet Ink Cartridge
17
C1Q26A HP 773A 775-ml Cyan Designjet Ink Cartridge
17
C1Q27A HP 773A 775-ml Photo Black Designjet Ink Cartridge
17
C1Q28A HP 773A 775-ml Light Gray Designjet Ink Cartridge
17
CH644A HP 771 Designjet Maintenance Cartridge
Original
HP large
format printing
materials
Q8000A
HP Premium Instant-dry Satin Photo Paper
(FSC® certied)
18 19
1524 mm x 30.5 m (60 in x 100 ft)
Q6578A
HP Universal Instant-dry Gloss Photo Paper
(FSC® certied)
18 19
1524 mm x 30.5 m (60 in x 100 ft)
Q8707A
HP Artist Matte Canvas 1524 mm x 15.2 m (60 in x 50 ft)
Q8750A
HP Premium Vivid Color Backlit Film
20
1524 mm x 30.5 m (60 in x 100 ft)
Service and support
H4518E HP Installation Service with Network Setup
U1ZS8E HP 2 years Next Business Day Onsite Support with DMR *
U1ZS9E HP 3 years Next Business Day Onsite Support with DMR *
U1Z T0E HP 5 years Next Business Day Onsite Support with DMR *
U1Z T2PE HP 1 years Post Warranty, Next Business Day Onsite Support with DMR *
U1Z T1PE HP 2 years Post Warranty, Next Business Day Onsite Support with DMR *
U1X V4E HP Preventive Maintenance Service
9
Mechanical printing time. Printed in Fast mode with HP Vivid Photo Inks.
10
Mechanical printing time. Printed with HP Vivid Photo Inks.
11
+/- 0.1% of the specied vector length or +/- 0.2 mm (whichever greater) at 23ºC (73ºF), 50-60% relative
humidity, on A0/E HP Matte Film in Best or Normal mode with HP Vivid Photo Inks.
12
Measured on HP Matte Film.
13
ICC absolute colorimetric accuracy on HP Premium Instant Dry Photo Paper with Original HP inks.
14
With HP Premium Instant-dry Gloss Photo Paper and Original HP inks, right after calibration.
15
With HP Premium Instant-dry Photo Gloss media with HP Vivid Photo Inks.
16
Based on 1 GB RAM. Expandable to 1.5 GB RAM through a Designjet qualied SODIMM included only in
the optional HP Designjet PostScript®/PDF Upgrade Kit accessory.
17
Only in selected US channels
18
BMG trademark license code FSC®-C115319, see fsc.org. HP trademark license code FSC®-C017543, see
fsc.org. Not all FSC®-certied products are available in all regions.
19
In North America, recyclable in consumer collection systems that can accept mixed paper (may not be
recyclable in your area).
20
HP Large Format Media take-back program availability varies. Recycling programs may not exist in your
area. See hp.com/recycle for details.
21
Display permanence rating for interior displays/away from direct sunlight, under glass by HP Image
Permanence Lab and/or by Wilhelm Imaging Research, Inc. on a range of HP media with Original HP inks.
See globalBMG.com/hp.
For more information, please visit
hp.com/go/DesignjetZ6800
© Copyright 2014 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and
services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty.
HP shall not be liable for technical or editorial errors or omissions contained herein.
Adobe, PostScript, and Adobe PostScript 3 are trademarks of Adobe Systems Incorporated. ENERGY STAR and the ENERGY STAR mark are registered U.S. marks. Windows is a
U.S. registered trademark of Microsoft Corporation. Mac and the Mac logo are trademarks of Apple Computer, Inc. PANTONE® is the property of Pantone, Inc.
4AA5-1278ENW, June 2014, Rev. 1
HP Designjet Support Services oer solutions for business critical environments — installation,
extended support and maintenance, as well as variety of value-added services. For more information,
please visit hp.com/go/designjet/support.
Use HP Vivid Photo Inks and printheads to experience consistent high-quality and reliable performance
that enable less downtime and increased productivity. These critical printing system components are
designed and engineered together to provide optimized eiciency, a wide color gamut, and prints with
over 200 years fade resistance.
21
For more information, visit hp.com/go/OriginalHPinks.
For the entire HP Large Format Printing Materials portfolio, please see globalBMG.com/hp.
* Defective Media Retention keeps your sensitive data safe. To comply with security regulations you can keep the defective
hard-drive or data-retentive memory component while getting a new replacement disk or memory.
