Figure5 Disconnect the PCIe power cable from PCIe fan
guide.
Figure6 Disconnect the front middle chassis fan cable
Figure7 Disconnect the front lower chassis fan cable
Figure8 Remove the PCIe fan guide from chassis
Figure9 Remove the front lower chassis fan from fan
guide.
Figure10 Remove the front middle chassis fan from fan
guide.
