HP Z8 G4 - Rear

Rear
Item Icon Component Item Icon Component
1
Power button
On: The computer is on.
Blinking white: The hard drive is
being accessed.
9
Power supply Built-In Self-Test
(BIST) light
2 Audio-in (microphone) jack 10 Power connector
3 Audio-out (headphone) jack 11 Security lock loop
4 PS/2 keyboard port 12
Ethernet ports (select products
only) (2)
5 USB 3.x SuperSpeed ports (6) 13 PS/2 mouse port
6 RJ-45 (network) jack 14 PCIe card release latches
7
RJ-45 (network) jack (AMT
enabled)
15 Security cable slot
8 PCIe card slots (7)
Components 11
