HP Z8 G4 User Manual

NOTE: Monitors with resolutions above 1920 x 1200 pixels at 60 Hz require a graphics card with
either Dual Link DVI (DL-DVI) or DisplayPort output. To get native resolution with DVI, you must use
a DL-DVI cable, not standard DVI-I or DVI-D cables.
HP computers do not support all graphics cards. Be sure that a new graphics card is supported
before purchasing it. See Finding supported graphics cards on page 17.
Many graphics cards provide more than two monitor outputs but limit you to using only two at a
time. Consult the graphics card documentation or look up information on the card according to the
procedure in Finding supported graphics cards on page 17.
Some graphics cards support multiple monitors by multiplexing the monitor signal across multiple
outputs. This might reduce graphics performance. Consult the graphics card documentation or look
up information on the card according to the procedure in
Finding supported graphics cards
on page 17.
Make sure the card outputs match the input required by the monitors. (See Identifying monitor
connection requirements on page 17.)
The dierent models of HP Z series computers have dierent limits on the mechanical size, data
speed, and power available for additional graphics cards. Note that the usual practical limit for
graphics cards is two per computer. See the Maintenance and Service Guide for expansion card slot
identication to make sure a new graphics card will work for your computer.
3. If you want to add a new graphics card or cards:
a. Determine which supported graphics card best ts your needs in terms of number of monitors,
compatibility with the monitors you plan to use, and performance. See Finding supported graphics
cards on page 17.
b. Make sure you have the correct drivers for the card. See http://www.hp.com for HP-qualied
drivers.
c. Install the graphics card according to the video instructions for your computer at
http://www.hp.com/go/sml.
d. Congure the monitor. For details, refer to Microsoft® Help or to http://www.microsoft.com.
For monitor setup in Linux, you can often use the settings tool for the graphics cards (e.g., NVIDIA
nvidia-settings or AMD Catalyst Control Center). In some recent Linux releases, the window
manager system (e.g., Gnome 3) preferences must also be modied.
TIP: To simplify troubleshooting of possible problems, enable the monitors one at a time: enable
the rst monitor and make sure it works properly before enabling the next monitor.
16 Chapter 3 Setting up the computer

HP Z8 G4 Specifications

General

Display included	No
Keyboard included	Yes
Power supply	1125 W
Operating system architecture	64-bit
Audio chip	Realtek ALC221
Product type	Workstation
Market positioning	Business
Motherboard chipset	Intel C622
Chassis type	Tower
Product color	Black
Country of origin	China
Number of 3.5\" bays	4
Number of 5.25\" bays	2
PCI Express x8 slots	3
Headphone outputs	1
HDMI ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	8
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
HDD speed	7200 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi
Card reader integrated	-
Total storage capacity	1000 GB
Memory slots	24x DIMM
Internal memory	8 GB
Memory channels	Hepta-channel
Memory clock speed	2666 MHz
Internal memory type	DDR4-SDRAM
Maximum internal memory	- GB
Memory layout (slots x size)	1 x 8 GB
Tcase	77 °C
Stepping	U0
Processor cache	11 MB
Processor model	4108
System bus rate	- GT/s
Processor socket	LGA 3647 (Socket P)
Processor threads	16
Processor codename	Skylake
Processor frequency	1.8 GHz
Processor cache type	L3
Processor lithography	14 nm
Processor manufacturer	Intel
PCI Express slots version	3.0
Processor boost frequency	3 GHz
Thermal Design Power (TDP)	85 W
Maximum number of PCI Express lanes	48
Memory clock speeds supported by processor	2400 MHz
Maximum internal memory supported by processor	768 GB
Scalability	2S
Processor code	SR3GJ
Processor ARK ID	123544
Intel TSX-NI version	1.00
Processor package size	76.0 x 56.5 mm
Supported instruction sets	AVX, AVX 2.0, AVX-512, SSE4.2

Weight and Dimensions

Depth	551.2 mm
Width	215.9 mm
Height	444.5 mm
Weight	22400 g
