HP Z800 Specification

Clear Password Jumper Yes
Serial Port Yes, on rear panel
Parallel Port No
Keyboard/Mouse Yes
Power Supply 850W 85% Efficient Wide-Ranging, Active PFC, Custom
1110W 89% Efficient Wide-Ranging, Active PFC, Custom
NOTE: The 1110W power supply can also supply 1250W of output power when the input voltage is greater
than 105V. If the input voltage is less than 105V, but greater than 90V for any reason, the maximum
power that can be drawn is 1110W. An uninterruptible power supply (UPS) is highly recommended if
1250W output power is desired.
Operating Voltage Range 90–269 VAC
Rated Voltage Range 850W:
100–127 VAC
200–240 VAC
1110W:
100 VAC
115 VAC
200–240 VAC
Rated Line Frequency 50–60 Hz
Operating Line Frequency
Range
47–66 Hz
393 – 407 Hz
Rated Input Current 850W: 11A @ 100–127V, 5.5A @ 200–240V
1110W: 12A @ 100V
1250W: 12A @ 115V, 10A @ 200–240V
Heat Dissipation 850W: Typical = 1707 BTU/hr, Max = 3558 BTU/hr
1110W: Typical = 2128 BTU/hr, Max-1 = 4457 BTU/hr, Max-2 = 5019 BTU/hr
Power Supply Fan 850W: 2x80x25 mm variable speed
1110W: 2x80x25 mm variable speed
ENERGY STAR® qualified
(Config Dependent)
Yes
80 PLUS Compliant Yes. 850W 85%
For the ECOs PSU Efficiency Report for the power supply, please go to this link:
http://www.plugloadsolutions.com/psu_reports/DELTA_DPS-850DB A_850W_80+_Report.pdf
Yes. 1110W 89%
For the ECOs PSU Efficiency Report for the power supply, please go to this link:
http://www.plugloadsolutions.com/psu_reports/DELTA_DPS-1050DBA_SO-035_1250W_Report.pdf
FEMP Standby Power
Compliant 115V (Wake-on
LAN disabled) (<2W in S5 -
Power Off)
Yes
Power consumption in
sleep mode (as defined by
ENERGY STAR) - Suspend
to RAM (S3)
850W: <20W
1110W: <20W
QuickSpecs
HP Z800 Workstation
System Technical Specifications
DA - 13278 North America — Version 56 — November 21, 2013 Page 19

HP Z800 Specifications

General

Processor cache	8 MB
Processor model	E5560
Processor frequency	2.8 GHz
Processor cache type	L2
Processor manufacturer	Intel
Processor front side bus	1333 MHz
Number of processors installed	2
Audio system	Integrated High Definition Realtek ALC262 Audio, optional Creative X-Fi Titanium PCIe Audio Card, optional HP Thin USB Powered Speakers
Product type	Workstation
Motherboard chipset	Intel® 5520
ECC	Yes
Maximum internal memory	192 GB
HDD speed	15000 RPM
HDD capacity	446 GB
HDD interface	Serial Attached SCSI (SAS)
Optical drive type	DVD Super Multi
Card reader integrated	No
I/O ports	Front: 3 USB 2.0, 1 IEEE 1394a, 1 microphone in, 1 headphone out; Rear: 6 USB 2.0, 1 IEEE 1394a, 1 audio in, 1 audio out, 1 microphone in, 2 PS/2, 2 RJ-45 to integrated Gigabit LAN, 1 serial; Internal: 3 USB 2.0
Headphone outputs	1
USB 2.0 ports quantity	9
Parallel ports quantity	0
Power supply	1110 W
Power consumption (typical)	240 W
Non-operating altitude	9100 m
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	8 - 90 %
Operating relative humidity (H-H)	8 - 85 %
Display	HP LP1965 19-inch LCD Monitor, HP LP2065 20-inch LCD Monitor, HP LP2275w 22-inch Widescreen LCD Monitor, HP LP2475w 24-inch Widescreen LCD Monitor, HP DreamColor LP2480zx Professional Display (24-inch widescreen), HP LP3065 30-inch Widescreen LCD Monitor (all sold separately)
Drive bays	3 external 5.25\
Graphics card	-
Keyboard type	HP PS/2 Standard Keyboard
Expansion slots	1 PCI, 1 PCI Express Gen1 (x8 mechanically, x4 electrically), 1 PCI Express Gen2 (x8 mechanically, x4 electrically), 2 PCI Express Gen2 (x16 mechanically, x8 electrically), 2 PCI Express Gen2 x16
Pointing device	HP USB Laser Scroll Mouse
Power requirements	1110 watts wide-ranging, active Power Factor Correction, direct connection Power Supplies
Storage drive type	300 GB 15000 rpm SAS 146 GB 15000 rpm SAS SAS 146 GB + 300 GB
HDD controller type	SATA (10000 rpm) SATA (7200 rpm) SAS (15000 rpm)
Video card features	No integrated Graphic Card
Maximum HDD capacity	450 GB
Storage drive controller	Integrated 6 channel SATA 3 Gb/s controller with RAID (0, 1, 5 or 10) capability, integrated 8 channel SAS controller with RAID (0, 1 or 10) capability, optional LSI 8888 ELP 8-port SAS HW with RAID (0, 1, 5 or 10) capability
Minimum storage drive space	146 GB
Operating system installed	Windows Vista Business
Compatible operating systems	HP Installer Kit for Linux
Chassis type	Mini Tower
Country of origin	China

Weight and Dimensions

Depth	526.5 mm
Width	203.5 mm
Height	445.1 mm
Weight	19500 g
