HP Z800 Specification

Data path speed 2.5 Gb/s per direction transfer rate
Data transfer mode Bus-master DMA
Power requirement 1.0 watts @ +3.3V AUX supply
Boot ROM support Yes
Network transfer rate 10BASE-T (half-duplex) 10 Mb/s
10BASE-T (full-duplex) 20 Mb/s
100BASE-TX (half-duplex) 100 Mb/s
100BASE-TX (full-duplex) 200 Mb/s
1000BASE-T (full-duplex) 2000 Mb/s
Microsoft Windows Vista Business 32 and 64, Microsoft
Windows XP
Management capabilities WOL, PXE 2.1 and ASF 2.0
PCI-X Connectors None
PCI Card Guide Yes
Wake on LAN Yes
Integrated Trusted Platform Module TPM 1.2
ASF 1.0 & 2.0 (Alert Standard Format) Yes
SATA Connectors 6 ports/connectors (Included are 4 eSATA configurable with
optional eSATA After-Market Option cable kit)
IEEE 1394 Connector(s) Front Yes, 1394a
Rear Yes, 1394a
Internal None
USB Connector(s) Front Yes, qty 3
Rear Yes, qty 6
Internal Yes, qty 3
3 USB 2.0 ports available by one 2x5 header and one 1x5
header: supports either up to two HP Internal USB Port Kits,
AMO- EM165AA, one on each header, or one USB Media Card
Reader. Each Internal Port Kit has two USB 2.0 connectors.
HD Integrated Audio Yes
Flash ROM Yes, SPI Rom
CPU Fan Header Yes, qty 2
Chassis Fan Header Yes, a single fan header for 2 fans.
Front PCI Fan Header Yes, qty 2
Front Control
Panel/Speaker Header
Yes
CMOS Battery Holder -
Lithium
Yes
Integrated Trusted
Platform Module
Integrated TPM 1.2
Power Supply Headers Yes: 9x2, 5x2, 4x2
Power Switch, Power LED
& Hard Drive LED Header
Yes
QuickSpecs
HP Z800 Workstation
System Technical Specifications
DA - 13278 North America — Version 56 — November 21, 2013 Page 18

HP Z800 Specifications

General

Processor cache	8 MB
Processor model	E5560
Processor frequency	2.8 GHz
Processor cache type	L2
Processor manufacturer	Intel
Processor front side bus	1333 MHz
Number of processors installed	2
Audio system	Integrated High Definition Realtek ALC262 Audio, optional Creative X-Fi Titanium PCIe Audio Card, optional HP Thin USB Powered Speakers
Product type	Workstation
Motherboard chipset	Intel® 5520
ECC	Yes
Maximum internal memory	192 GB
HDD speed	15000 RPM
HDD capacity	446 GB
HDD interface	Serial Attached SCSI (SAS)
Optical drive type	DVD Super Multi
Card reader integrated	No
I/O ports	Front: 3 USB 2.0, 1 IEEE 1394a, 1 microphone in, 1 headphone out; Rear: 6 USB 2.0, 1 IEEE 1394a, 1 audio in, 1 audio out, 1 microphone in, 2 PS/2, 2 RJ-45 to integrated Gigabit LAN, 1 serial; Internal: 3 USB 2.0
Headphone outputs	1
USB 2.0 ports quantity	9
Parallel ports quantity	0
Power supply	1110 W
Power consumption (typical)	240 W
Non-operating altitude	9100 m
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	8 - 90 %
Operating relative humidity (H-H)	8 - 85 %
Display	HP LP1965 19-inch LCD Monitor, HP LP2065 20-inch LCD Monitor, HP LP2275w 22-inch Widescreen LCD Monitor, HP LP2475w 24-inch Widescreen LCD Monitor, HP DreamColor LP2480zx Professional Display (24-inch widescreen), HP LP3065 30-inch Widescreen LCD Monitor (all sold separately)
Drive bays	3 external 5.25\
Graphics card	-
Keyboard type	HP PS/2 Standard Keyboard
Expansion slots	1 PCI, 1 PCI Express Gen1 (x8 mechanically, x4 electrically), 1 PCI Express Gen2 (x8 mechanically, x4 electrically), 2 PCI Express Gen2 (x16 mechanically, x8 electrically), 2 PCI Express Gen2 x16
Pointing device	HP USB Laser Scroll Mouse
Power requirements	1110 watts wide-ranging, active Power Factor Correction, direct connection Power Supplies
Storage drive type	300 GB 15000 rpm SAS 146 GB 15000 rpm SAS SAS 146 GB + 300 GB
HDD controller type	SATA (10000 rpm) SATA (7200 rpm) SAS (15000 rpm)
Video card features	No integrated Graphic Card
Maximum HDD capacity	450 GB
Storage drive controller	Integrated 6 channel SATA 3 Gb/s controller with RAID (0, 1, 5 or 10) capability, integrated 8 channel SAS controller with RAID (0, 1 or 10) capability, optional LSI 8888 ELP 8-port SAS HW with RAID (0, 1, 5 or 10) capability
Minimum storage drive space	146 GB
Operating system installed	Windows Vista Business
Compatible operating systems	HP Installer Kit for Linux
Chassis type	Mini Tower
Country of origin	China

Weight and Dimensions

Depth	526.5 mm
Width	203.5 mm
Height	445.1 mm
Weight	19500 g
